IRS2113STRPBF
IRS2113STRPBF
376-IRS2113STRPBF
16-SOIC (0.295, 7.50mm Width)
Surface Mount Tape & Reel (TR) Active EAR99 Gate Drivers ICs Non-Inverting 2 600V V 16-SOIC (0.295, 7.50mm Width) IRS2113SPBF Half-Bridge
In Stock : 999
Share
Please send RFQ, we will respond immediately.
Product Details
Purchasing and Inquiry
IRS2113STRPBF Overview
For greater flexibility, the 16-SOIC (0.295, 7.50mm Width) package is adopted.A packaging method of Tape & Reel (TR) is indicated.Configuration is based on 2 drivers.In this case, gate drivers is mounted along the way of Surface Mount.By using 10V~20V supply voltage, it is able to demonstrate its superiority.This device is designed with a IGBT, N-Channel MOSFET gate type.This device is allowed to operate in a temperature range of -40°C~150°C TJ.The input type is Non-Inverting.Its configuration starts with 16 terminations.The base part number IRS2113SPBF refers to a number of related parts.The mount method is Surface Mount.Devices have 16 pins available.Mosfet driver is designed specifically to run on 15V volts of power.Mosfet driver is equipped wMosfet driverh an interface chip BUFFER OR INVERTER BASED PERIPHERAL DRIVER.As a maximum, there is 2.5A limit to the output current.There are several useful electronic components found in its subcategory of MOSFET Drivers.High-side voltage - Max (Bootstrap) can be as low as 600V.Mosfet driver supports an output current of 2.5A.Based on its maximum power dissipation of 1.25W, it is clear that it is capable of transferring and conducting power loss without overheating.The supply current should be kept at 340μA to ensure higher stability.With its power supplies of 15V, it solves the problems of power supply for a variety of applications.Mosfet gate drivers outputs 10V as voltage.
IRS2113STRPBF Features
Embedded in the Tape & Reel (TR) package
2 drivers
Employing a gate type of IGBT, N-Channel MOSFET
16 pins
High-side voltage - Max (Bootstrap) of 600V
Maximum power dissipation of 1.25W
IRS2113STRPBF Applications
There are a lot of Infineon Technologies IRS2113STRPBF gate drivers applications.
- High-speed communications
- Power factor correction (PFC) circuits
- Isolated switch mode power supplies (SMPS)
- Active filtering
- 3-Phase Motor Inverter Driver
- Video amplifiers
- DC-DC Converters
- Telecom switch mode power supplies
- Smart Phones
- Active Clamp Flyback or Forward and Synchronous Rectifier
