Heat Sinks

Name	Manufacturer	Pricing(USD)	Quantity	Datasheet	Factory Lead Time	Mount	Material	Shape	Packaging	Published	Series	Part Status	Moisture Sensitivity Level (MSL)	Color	Depth	Diameter	Length	RoHS Status	Lead Free	Contact Plating	Radiation Hardening	Number of Pins	Package / Case	REACH SVHC	Height	Width	Type	Body Material	Power Dissipation	Natural Thermal Resistance	Thermal Resistance @ Natural	Height Off Base (Height of Fin)	Attachment Method	Package Cooled	Thermal Resistance @ Forced Air Flow	Material Finish	Power Dissipation @ Temperature Rise
519703B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download		Bolt	Aluminum	Rhombus		2007		Active	Not Applicable				1.550 39.37mm	RoHS Compliant	Lead Free							1.550 39.37mm	Board Level				4.80°C/W	1.500 38.10mm	Bolt On	TO-3	2.00°C/W @ 400 LFM	Black Anodized	6.0W @ 30°C
637302F00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Pin Fins		2016		Active	Not Applicable				48.000 1219.20mm	RoHS Compliant								3.000 76.20mm	Top Mount, Extrusion					2.250 57.15mm	Adhesive		1.00°C/W @ 200 LFM
533202B02500G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download		Bolt, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable				2.000 50.80mm	RoHS Compliant								1.375 34.93mm	Board Level, Vertical				9.00°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220	3.00°C/W @ 400 LFM	Black Anodized	3.0W @ 30°C
531002B02500G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins	Bulk	2001		Active	Not Applicable	Black	12.7mm		1.000 25.40mm	RoHS Compliant	Lead Free	Tin	No		Radial	No SVHC	12.7mm	1.375 34.93mm	Board Level, Vertical				13.40°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220	4.00°C/W @ 400 LFM	Black Anodized	2.0W @ 30°C
PF750G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	8 Weeks	PCB, Through Hole	Aluminum	Rectangular		1999		Active	Not Applicable		11mm		0.866 22.00mm	RoHS Compliant	Lead Free		No		TO-220	No SVHC	19mm	0.433 11.00mm	Board Level, Vertical			20 °C/W		0.748 19.00mm	Clip and PC Pin	TO-220		Tin
335314B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download						2007		Active	Not Applicable				27mm	RoHS Compliant		Tin			BGA				Passive
574602B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	10.03mm		0.690 17.53mm	RoHS Compliant	Lead Free				TO-220		17.53mm	0.860 21.84mm	Board Level				21.60°C/W	0.395 10.03mm	Clip	TO-220	6.00°C/W @ 600 LFM	Black Anodized	3.0W @ 60°C
374024B00035G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	8 Weeks		Aluminum	Square, Pin Fins		2002		Active	Not Applicable	Black	23mm		0.906 23.01mm	RoHS Compliant	Lead Free		No		BGA	No SVHC	10mm	0.906 23.01mm	Top Mount				40.00°C/W	0.394 10.00mm	Thermal Tape, Adhesive (Included)	BGA	11.70°C/W @ 200 LFM	Black Anodized	1.0W @ 40°C
573100D00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Surface Mount	Aluminum	Rectangular, Fins	Box	2007	5731	Active	1 (Unlimited)		8mm		0.315 8.00mm	RoHS Compliant	Lead Free	Tin	No		TO-252	No SVHC	10.16mm	0.900 22.86mm	Top Mount				15.00°C/W	0.400 10.16mm	SMD Pad	TO-252 (DPak)	12.50°C/W @ 600 LFM	Tin	0.8W @ 30°C
647064	Aavid, Thermal Division of Boyd Corporation	28.9725	Add to Cart Min: 1 Mult: 1				Copper	Rectangular, Fins				Active	Not Applicable				4.252 108.00mm	RoHS Compliant								3.071 78.00mm	Top Mount					2.519 64.00mm	Bolt On	Intel® Xeon® CPU
1130BG	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1		9 Weeks		Aluminum	Cylindrical				Active	Not Applicable			0.450 11.43mm	0.400 10.16mm	RoHS Compliant	Lead Free							0.375 9.50mm	Board Level				15°C/W	0.450 11.43mm	Press Fit	TO-5		Black Anodized
533402B02552G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins	Box	2007		Active	Not Applicable	Black	25.4mm		1.650 41.91mm	RoHS Compliant	Lead Free				TO-220		38.1mm	1.000 25.40mm	Board Level, Vertical				5.00°C/W	1.500 38.10mm	Clip and PC Pin	TO-220	2.00°C/W @ 500 LFM	Black Anodized	8.0W @ 40°C
575002D00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Screw		Rectangular, Fins		2007		Active	Not Applicable				1.180 29.97mm	RoHS Compliant					TO-220		29.97mm	1.000 25.40mm	Board Level, Vertical				13.60°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220	5.00°C/W @ 400 LFM	Tin	1.0W @ 20°C
320105B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	9 Weeks	Press Fit	Aluminum	Cylindrical		2007		Active	Not Applicable	Black		0.318 8.07mm ID 0.500 12.70mm OD	6.35mm	RoHS Compliant					TO-5	Unknown	6.35mm		Board Level				63.00°C/W	0.250 6.35mm	Press Fit	TO-5	35.00°C/W @ 200 LFM	Black Anodized	0.6W @ 40°C
550402B00000	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download		Bolt, PC Pin	Aluminum	Rectangular		2007		Active	Not Applicable				1.675 42.55mm	Non-RoHS Compliant								1.000 25.40mm	Board Level, Vertical				11.20°C/W	1.000 25.40mm	Bolt On and PC Pin	TO-220	4.00°C/W @ 300 LFM	Black Anodized	4.0W @ 40°C
573400D00010G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	PCB, Surface Mount	Copper	Rectangular, Fins	Tape & Reel (TR)	2007		Active	Not Applicable	Grey	12.7mm		0.500 12.70mm	RoHS Compliant	Lead Free	Tin	No		TO-268	No SVHC	10.2mm	1.220 30.99mm	Top Mount				14.00°C/W	0.401 10.20mm	SMD Pad	TO-268 (D3Pak)	4.00°C/W @ 600 LFM	Tin	1.0W @ 20°C
592502B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download		Bolt	Aluminum	Rectangular, Fins		2007		Active	Not Applicable				1.250 31.75mm	RoHS Compliant					TO-220			0.875 22.22mm	Board Level				22.00°C/W	0.250 6.35mm	Bolt On	TO-220	10.00°C/W @ 200 LFM	Black Anodized	1.5W @ 40°C
M48118B011000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Angled Fins			Max Clip System™	Active	Not Applicable				1.180 29.97mm									0.866 22.00mm	Board Level, Vertical					1.516 38.50mm	Clip and PC Pin	TO-126, TO-220, TO-247		Black Anodized
529901B02100G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	50.8mm		2.000 50.80mm	RoHS Compliant	Lead Free		No		Radial		50.8mm	1.650 41.91mm	Board Level, Vertical				4.50°C/W	1.000 25.40mm	Bolt On and PC Pin	TO-218	1.00°C/W @ 800 LFM	Black Anodized	12.0W @ 50°C
7140DG	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	9 Weeks	Clip, PC Pin	Copper	Rectangular, Fins		2007		Active	Not Applicable		17.78mm		0.700 17.78mm	RoHS Compliant	Lead Free		No				9.52mm	0.900 22.86mm	Board Level				20.80°C/W	0.375 9.52mm	Clip and PC Pin	TO-220	10.00°C/W @ 200 LFM	Tin	1.5W @ 50°C
529701B02100G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins		2007		Active	Not Applicable				1.000 25.40mm	RoHS Compliant	Lead Free				Radial			1.650 41.91mm	Board Level, Vertical				5.50°C/W	1.000 25.40mm	Bolt On and PC Pin	TO-218	4.00°C/W @ 200 LFM	Black Anodized	12.0W @ 70°C
326005R00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	9 Weeks	Press Fit	Aluminum	Cylindrical		2006		Active	Not Applicable	Red		0.318 8.07mm ID 0.500 12.70mm OD		RoHS Compliant	Lead Free				Radial		9.53mm		Board Level				57.00°C/W	0.375 9.52mm	Press Fit	TO-5	30.00°C/W @ 200 LFM	Red Anodized	1.8W @ 90°C
6045BG	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	9 Weeks							Active	Not Applicable		8.89mm		25.4mm	RoHS Compliant					TO-220				Passive
335814B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	9 Weeks					2007		Active	Not Applicable				30.1mm	RoHS Compliant		Tin			BGA				Passive
326005B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	9 Weeks	Press Fit	Aluminum	Cylindrical	Bulk	2003		Active	Not Applicable	Black		0.318 8.07mm ID 0.500 12.70mm OD	9.53mm	RoHS Compliant	Lead Free		No		TO-5		9.53mm		Board Level		1W		57.00°C/W	0.375 9.52mm	Press Fit	TO-5	30.00°C/W @ 200 LFM	Black Anodized	1.8W @ 90°C
568003B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1		8 Weeks		Aluminum	Square				Active	Not Applicable				1.810 45.97mm	RoHS Compliant								1.810 45.97mm	Board Level				8.00°C/W	0.500 12.70mm	Bolt On	TO-3	1.50°C/W @ 400 LFM	Black Anodized	5.0W @ 50°C
374724B00032G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	8 Weeks	Bolt	Aluminum	Square, Pin Fins	Bulk	2002		Active	Not Applicable	Black	35mm		1.378 35.00mm	RoHS Compliant	Lead Free				BGA	No SVHC	18mm	1.378 35.00mm	Top Mount	Metal			15.30°C/W	0.709 18.00mm	Thermal Tape, Adhesive (Included)	BGA	5.20°C/W @ 200 LFM	Black Anodized	3.0W @ 50°C
580100B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Press Fit	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	15.24mm		0.562 14.27mm	RoHS Compliant	Lead Free		No	8		No SVHC	11.43mm	0.600 15.24mm	Top Mount	Aluminium			30.00°C/W	0.450 11.43mm	Press Fit, Slide On	8-DIP	8.00°C/W @ 500 LFM	Black Anodized	1.0W @ 30°C
342949	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	6 Weeks	Push Pin	Copper	Square, Fins				Active	Not Applicable				3.150 80.00mm	RoHS Compliant								3.150 80.00mm	Top Mount				5.10°C/W	0.472 12.00mm	Push Pin	BGA	1.20°C/W @ 200 LFM	AavSHIELD 3C
325705R00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	9 Weeks	Press Fit	Aluminum	Cylindrical		2007		Active	Not Applicable			0.318 8.07mm ID 0.500 12.70mm OD		RoHS Compliant					Radial				Board Level				60.00°C/W	0.250 6.35mm	Press Fit	TO-5	35.00°C/W @ 200 LFM	Red Anodized	1.0W @ 60°C
