Heat Sinks

Name	Manufacturer	Quantity	Datasheet	Factory Lead Time	Mount	Material	Shape	Packaging	Published	Series	Part Status	Moisture Sensitivity Level (MSL)	Color	Depth	Diameter	Length	RoHS Status	Lead Free	Radiation Hardening	Number of Pins	Package / Case	REACH SVHC	Height	Width	Weight	Packing Method	Type	Body Material	Power Dissipation	Natural Thermal Resistance	Thermal Resistance @ Natural	Height Off Base (Height of Fin)	Profile	Fin Orientation	Attachment Method	Package Cooled	Thermal Resistance @ Forced Air Flow	Material Finish	Power Dissipation @ Temperature Rise	Device Used On
502006B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rhombus		2007		Active	Not Applicable	Black			1.550 39.37mm	RoHS Compliant				TO-66		31.75mm	1.040 26.42mm			Board Level				8.00°C/W	1.250 31.75mm			Bolt On	TO-66	4.00°C/W @ 200 LFM	Black Anodized	7.0W @ 50°C
574102B03300G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin, Solder	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			0.750 19.05mm	RoHS Compliant				TO-220		19.05mm	0.860 21.84mm			Board Level, Vertical				23.20°C/W	0.395 10.03mm			Clip and PC Pin	TO-220	8.00°C/W @ 500 LFM	Black Anodized	1.5W @ 40°C
374724B60024G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	8 Weeks	Solder	Aluminum	Square, Pin Fins	Bulk	2002		Active	Not Applicable	Black	35mm		1.378 35.00mm	RoHS Compliant	Lead Free	No		BGA	No SVHC	18mm	1.378 35.00mm			Top Mount				15.30°C/W	0.709 18.00mm			Solder Anchor	BGA	5.20°C/W @ 200 LFM	Black Anodized	3.0W @ 50°C
579103B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rhombus		2007		Active	Not Applicable	Black	28.57mm	1.125 28.57mm OD	1.540 39.12mm	RoHS Compliant	Lead Free			TO-3	No SVHC	22.1mm	28.57mm			Top Mount				12.50°C/W	0.870 22.10mm			Bolt On	TO-3	4.00°C/W @ 600 LFM	Black Anodized	2.5W @ 40°C
501503B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rhombus	Bulk	2003		Active	Not Applicable	Black	35.56mm		1.880 47.75mm	RoHS Compliant	Lead Free	No		TO-3	No SVHC	25.4mm	1.400 35.56mm	113.398093g		Board Level		12W		8.40°C/W	1.000 25.40mm			Bolt On	TO-3	2.00°C/W @ 500 LFM	Black Anodized	5.0W @ 40°C
645002F00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Pin Fins		2016		Active	Not Applicable				48.000 1219.20mm	RoHS Compliant							5.900 149.86mm			Top Mount, Extrusion					1.063 27.00mm			Adhesive		0.50°C/W @ 500 LFM
574204B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip	Aluminum	Rectangular	Bulk	2007		Active	Not Applicable	Black			0.900 22.86mm	RoHS Compliant	Lead Free			TO-202		22.86mm	1.020 25.91mm			Board Level				16.80°C/W	0.420 10.67mm			Clip	TO-202	8.00°C/W @ 200 LFM	Black Anodized	1.0W @ 20°C
568303B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	8 Weeks		Aluminum	Square	Bulk	2003		Active	Not Applicable	Black			1.810 45.97mm	RoHS Compliant	Lead Free			TO-3		31.75mm	1.810 45.97mm			Board Level				5.40°C/W	1.250 31.75mm			Bolt On	TO-3	2.50°C/W @ 200 LFM	Black Anodized	5.0W @ 30°C
533702B02552G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			1.000 25.40mm	RoHS Compliant					No SVHC	25.4mm	1.650 41.91mm			Board Level, Vertical				5.70°C/W	1.000 25.40mm			Clip and PC Pin	TO-220	4.00°C/W @ 200 LFM	Black Anodized	12.0W @ 70°C
566010B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip	Aluminum	Rectangular, Fins		2007		Active	Not Applicable		25.4mm		1.220 30.99mm	RoHS Compliant				SIP			1.000 25.40mm			Board Level				11.50°C/W	0.500 12.70mm			Clip	Multiwatt, SIP	4.00°C/W @ 300 LFM	Black Anodized	3.0W @ 40°C
7106D/TRG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Surface Mount	Copper	Rectangular, Fins	Tape & Reel (TR)	2007		Active	1 (Unlimited)				0.590 15.00mm	RoHS Compliant	Lead Free			TO-263			1.020 25.91mm		TAPE AND REEL	Top Mount			15 °C/W		0.375 9.52mm			SMD Pad	TO-263 (D2Pak), PowerSO-10 (MO-184), SO-10	5.00°C/W @ 400 LFM	Tin	2.0W @ 40°C	IC
530102B00150G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip	Aluminum	Square, Fins	Bulk	2007		Active	Not Applicable	Black	12.45mm		1.750 44.45mm	RoHS Compliant	Lead Free	No		TO-220	No SVHC	44.45mm	0.490 12.44mm			Board Level, Vertical				6.30°C/W	1.750 44.45mm			Clip and Board Mounts	TO-220	1.50°C/W @ 400 LFM	Black Anodized	4.0W @ 30°C
513001B02500G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins	Box	2007		Active	Not Applicable	Black	12.7mm		1.000 25.40mm	RoHS Compliant	Lead Free			TO-218		25.4mm	1.375 34.93mm			Board Level, Vertical				13.40°C/W	0.500 12.70mm			Bolt On and PC Pin	TO-218, TO-247	4.00°C/W @ 400 LFM	Black Anodized	2.0W @ 30°C
592902B03400G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins		2007	Channel 5900	Active	Not Applicable				0.980 24.89mm	RoHS Compliant				TO-220			0.942 23.93mm			Board Level, Vertical				17.90°C/W	0.500 12.70mm			Bolt On and PC Pin	TO-220	6.00°C/W @ 400 LFM	Black Anodized	1.0W @ 20°C
371824B00032G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	8 Weeks	Surface Mount	Aluminum	Square, Pin Fins	Bulk	2002		Active	Not Applicable	Black	35mm		1.378 35.00mm	RoHS Compliant	Lead Free	No		BGA	No SVHC	7mm	1.378 35.00mm			Top Mount				31.90°C/W	0.275 7.00mm			Thermal Tape, Adhesive (Included)	BGA	9.70°C/W @ 200 LFM	Black Anodized	1.5W @ 50°C
578105B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	PCB, Press Fit, Through Hole	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	10.03mm	0.316 8.03mm ID	0.406 10.31mm	RoHS Compliant	Lead Free	No		TO-5		3.96mm	0.830 21.08mm			Top Mount				40.00°C/W	0.395 10.03mm			Press Fit	TO-5	35.00°C/W @ 200 LFM	Black Anodized	1.0W @ 40°C
532802B02500G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			2.500 63.50mm	RoHS Compliant	Lead Free			Radial		63.5mm	1.650 41.91mm			Board Level, Vertical				4.20°C/W	1.000 25.40mm			Bolt On and PC Pin	TO-220	2.00°C/W @ 200 LFM	Black Anodized	6.0W @ 30°C
593101B03600G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	12.7mm		1.640 41.66mm	RoHS Compliant	Lead Free			TO-218	Unknown	41.66mm	1.700 43.18mm			Board Level, Vertical				8.60°C/W	0.500 12.70mm			Bolt On and PC Pin	TO-218, TO-247	4.00°C/W @ 300 LFM	Black Anodized	6.0W @ 50°C
533201B02500G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Bolt, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable				2.000 50.80mm	RoHS Compliant							1.375 34.93mm			Board Level, Vertical				9.00°C/W	0.500 12.70mm			Bolt On and PC Pin	TO-218, TO-247	3.00°C/W @ 400 LFM	Black Anodized	3.0W @ 30°C
6261B-MT5G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download						2007		Active	Not Applicable					RoHS Compliant
574902B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	10.03mm		1.375 34.93mm	RoHS Compliant		No		TO-220		34.93mm	0.860 21.84mm			Board Level				16.00°C/W	0.395 10.03mm			Clip	TO-220	6.00°C/W @ 400 LFM	Black Anodized	2.5W @ 40°C
501200B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Adhesive	Aluminum	Rectangular, Fins	Bulk	2007		Active	Not Applicable	Black	6.35mm		0.250 6.35mm	RoHS Compliant	Lead Free	No	14		No SVHC	4.82mm	0.731 18.57mm			Top Mount				68.00°C/W	0.190 4.83mm			Thermal Tape, Adhesive (Not Included)	14-DIP and 16-DIP	50.00°C/W @ 200 LFM	Black Anodized	0.4W @ 30°C
7142DG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Clip	Copper	Rectangular, Fins		2007		Active	Not Applicable				0.780 19.81mm	RoHS Compliant	Lead Free				Unknown	19.81mm	0.520 13.21mm			Board Level				20.30°C/W	0.515 13.08mm	U	TRANSVERSE	Clip and Board Locks	TO-220	8.00°C/W @ 400 LFM	Tin	1.0W @ 30°C
533101B02551G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable		12.7mm		1.500 38.10mm	RoHS Compliant				TO-218			1.375 34.93mm			Board Level, Vertical				11.00°C/W	0.500 12.70mm			Clip and PC Pin	TO-218, TO-247	3.00°C/W @ 500 LFM	Black Anodized	8.0W @ 80°C
320205B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Press Fit	Aluminum	Cylindrical		2007		Active	Not Applicable	Black		0.305 7.75mm ID 0.500 12.70mm OD	12.7mm	RoHS Compliant	Lead Free			TO-5		6.35mm				Board Level		1W		63.00°C/W	0.250 6.35mm			Press Fit	TO-5	35.00°C/W @ 200 LFM	Black Anodized	0.6W @ 40°C
7023B-MTG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	24.13mm		1.950 49.53mm	RoHS Compliant	Lead Free	No		TO-220	Unknown	50mm	1.900 48.26mm	113.398093g		Board Level, Vertical				4.40°C/W	0.950 24.13mm			Bolt On and PC Pin	TO-220	2.50°C/W @ 400 LFM	Black Anodized	3.0W @ 20°C
575903B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rhombus		2007		Active	Not Applicable	Black	32.77mm		1.630 41.40mm	RoHS Compliant	Lead Free			TO-3		31.75mm	1.290 32.77mm			Board Level				9.80°C/W	1.250 31.75mm			Bolt On	TO-3	3.00°C/W @ 300 LFM	Black Anodized	7.0W @ 70°C
780102F00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Pin Fins		2016		Active	Not Applicable				49.500 1257.30mm	RoHS Compliant							1.339 34.00mm			Board Level, Vertical, Extrusion					2.953 75.00mm			PC Pin
574502B03200G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin, Solder	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	10.03mm		0.750 19.05mm	RoHS Compliant	Lead Free	No		TO-220	No SVHC	19.05mm	0.860 21.84mm			Board Level, Vertical				21.20°C/W	0.395 10.03mm			Clip and PC Pin	TO-220	6.00°C/W @ 600 LFM	Black Anodized	3.0W @ 60°C
375424B00034G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	8 Weeks		Aluminium, Anodized, Plastic			2007		Active	Not Applicable		15.2mm		15.2mm	RoHS Compliant	Lead Free	No		BGA						Passive	Plastic		62.5 °C/W
