Heat Sinks

Name	Manufacturer	Quantity	Datasheet	Factory Lead Time	Mount	Material	Shape	Packaging	Published	Series	Part Status	Moisture Sensitivity Level (MSL)	Color	Depth	Diameter	Length	RoHS Status	Lead Free	Contact Plating	Radiation Hardening	Number of Pins	Package / Case	REACH SVHC	Height	Width	Weight	Type	Body Material	Power Dissipation	Natural Thermal Resistance	Thermal Resistance @ Natural	Height Off Base (Height of Fin)	Attachment Method	Package Cooled	Thermal Resistance @ Forced Air Flow	Material Finish	Power Dissipation @ Temperature Rise
780152F00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Pin Fins		2016		Active	Not Applicable				49.500 1257.30mm	RoHS Compliant								1.063 27.00mm		Board Level, Vertical, Extrusion					1.970 50.04mm	Clip and PC Pin
577102B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rectangular, Fins	Bulk	2001		Active	Not Applicable	Black	9.52mm		0.750 19.05mm	RoHS Compliant	Lead Free		No		TO-220	No SVHC	9.52mm	0.520 13.21mm	113.398093g	Board Level				25.90°C/W	0.375 9.52mm	Bolt On	TO-220	12.00°C/W @ 200 LFM	Black Anodized	3.0W @ 80°C
7109DG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Surface Mount	Copper	Rectangular, Fins		2006		Active	Not Applicable	Black	19.38mm		0.763 19.38mm	RoHS Compliant	Lead Free	Tin	No		TO-263	No SVHC	11mm	1.000 25.40mm		Top Mount				11.00°C/W	0.450 11.43mm	SMD Pad	TO-263 (D2Pak)	3.00°C/W @ 300 LFM	Tin	2.0W @ 30°C
M48059B011000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Angled Fins			Max Clip System™	Active	Not Applicable				0.590 15.00mm									0.866 22.00mm		Board Level, Vertical					1.516 38.50mm	Clip and PC Pin	TO-126, TO-220, TO-247		Black Anodized
580300B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	8 Weeks	Press Fit	Aluminum	Rectangular, Fins	Bulk	2003		Active	Not Applicable	Black			1.125 28.58mm	RoHS Compliant	Lead Free			18			14.12mm	0.700 17.78mm		Top Mount				39.00°C/W	0.556 14.12mm	Press Fit, Slide On	18-DIP	20.00°C/W @ 200 LFM	Black Anodized	2.0W @ 60°C
574402B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Clip	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			0.750 19.05mm	RoHS Compliant					TO-220		19.05mm	0.860 21.84mm		Board Level				23.20°C/W	0.395 10.03mm	Clip	TO-220	6.00°C/W @ 600 LFM	Black Anodized	3.0W @ 60°C
2281B	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks		Aluminum					Active	Not Applicable					Non-RoHS Compliant																			Black Anodized
M48118B011000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Angled Fins			Max Clip System™	Active	Not Applicable				1.180 29.97mm									0.866 22.00mm		Board Level, Vertical					1.516 38.50mm	Clip and PC Pin	TO-126, TO-220, TO-247		Black Anodized
529801B00000	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Bolt	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			1.500 38.10mm	Non-RoHS Compliant					Radial		25.4mm	1.650 41.91mm		Board Level				5.00°C/W	1.000 25.40mm	Bolt On	TO-218	3.00°C/W @ 200 LFM	Black Anodized	5.0W @ 30°C
6271B	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download			Aluminum					Active	Not Applicable					Non-RoHS Compliant	Lead Free																		Black Anodized
506007B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, Screw	Aluminum	Rectangular, Fins		2003		Active	Not Applicable	Black	44.45mm		2.000 50.80mm	RoHS Compliant	Lead Free		No		TO-3	No SVHC	10mm	1.750 44.45mm	113.398093g	Board Level	Aluminium			7.00°C/W	0.375 9.52mm	Bolt On	TO-3	3.00°C/W @ 400 LFM	Black Anodized	10.0W @ 70°C
6225B-MTG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin	Aluminum	Rectangular, Fins		2006		Active	Not Applicable	Black	8mm		1.070 27.18mm	RoHS Compliant	Lead Free		No		TO-220	Unknown	27.18mm	1.024 26.00mm		Board Level, Vertical				15.00°C/W	0.315 8.00mm	Bolt On and PC Pin	TO-220	3.00°C/W @ 700 LFM	Black Anodized	2.0W @ 40°C
566902B04000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins	Box	2007		Active	Not Applicable	Black	12.7mm		0.850 21.59mm	RoHS Compliant	Lead Free				TO-220		21.59mm	1.000 25.40mm		Board Level, Vertical				18.80°C/W	0.500 12.70mm	Clip and PC Pin	TO-220, TO-262	9.00°C/W @ 200 LFM	Black Anodized	2.0W @ 40°C
7109D/TRG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Surface Mount	Copper	Rectangular, Fins	Tape & Reel (TR)	2007		Active	Not Applicable		19.38mm		0.763 19.38mm	RoHS Compliant	Lead Free		No		TO-220		11.43mm	1.000 25.40mm		Top Mount				11.00°C/W	0.450 11.43mm	SMD Pad	TO-263 (D2Pak)	3.00°C/W @ 300 LFM	Tin	2.0W @ 30°C
550402B00000	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Bolt, PC Pin	Aluminum	Rectangular		2007		Active	Not Applicable				1.675 42.55mm	Non-RoHS Compliant								1.000 25.40mm		Board Level, Vertical				11.20°C/W	1.000 25.40mm	Bolt On and PC Pin	TO-220	4.00°C/W @ 300 LFM	Black Anodized	4.0W @ 40°C
529701B02500G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	25.4mm		1.000 25.40mm	RoHS Compliant	Lead Free		No		Radial	No SVHC	25.4mm	1.650 41.91mm		Board Level, Vertical				5.50°C/W	1.000 25.40mm	Bolt On and PC Pin	TO-218	4.00°C/W @ 200 LFM	Black Anodized	12.0W @ 70°C
574102B03700G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin, Solder	Aluminum	Rectangular		2007		Active	Not Applicable	Black			0.750 19.05mm	RoHS Compliant	Lead Free				TO-220		19.05mm	0.860 21.84mm		Board Level, Vertical				23.20°C/W	0.395 10.03mm	Clip and PC Pin	TO-220	8.00°C/W @ 500 LFM	Black Anodized	2.0W @ 50°C
579604B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			0.900 22.86mm	RoHS Compliant					TO-202		22.86mm	0.745 18.92mm		Board Level				24.00°C/W	0.420 10.67mm	Clip	TO-202	6.00°C/W @ 700 LFM	Black Anodized	1.5W @ 40°C
573400D00010G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	PCB, Surface Mount	Copper	Rectangular, Fins	Tape & Reel (TR)	2007		Active	Not Applicable	Grey	12.7mm		0.500 12.70mm	RoHS Compliant	Lead Free	Tin	No		TO-268	No SVHC	10.2mm	1.220 30.99mm		Top Mount				14.00°C/W	0.401 10.20mm	SMD Pad	TO-268 (D3Pak)	4.00°C/W @ 600 LFM	Tin	1.0W @ 20°C
573902B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	12.7mm		1.500 38.10mm	RoHS Compliant	Lead Free	Tin			TO-220	No SVHC	38.1mm	0.500 12.70mm		Board Level				18.80°C/W	0.500 12.70mm	Clip	TO-220	7.00°C/W @ 200 LFM	Black Anodized	3.0W @ 60°C
502203B00000	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rhombus	Bulk	2007		Active	Not Applicable	Black			1.630 41.40mm	RoHS Compliant	Lead Free						19.1mm	1.290 32.77mm		Board Level		6W			0.750 19.05mm	Bolt On			Black Anodized
533422B02552G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	25.4mm		1.650 41.91mm	RoHS Compliant	Lead Free				TO-220	Unknown	38.1mm	1.000 25.40mm		Board Level, Vertical			5 °C/W		1.500 38.10mm	Clip and PC Pin	TO-220 (Dual)	3.00°C/W @ 200 LFM	Black Anodized	10.0W @ 50°C
531302B02500G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins	Bulk	2007		Active	Not Applicable	Black	12.7mm		2.500 63.50mm	RoHS Compliant	Lead Free		No		TO-202	No SVHC	63.5mm	1.375 34.93mm		Board Level, Vertical				8.00°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220, TO-202	4.00°C/W @ 500 LFM	Black Anodized	6.0W @ 40°C
530101B00100G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, Clip, Solder	Aluminum	Square, Fins		2007		Active	Not Applicable	Black	12.45mm		1.750 44.45mm	RoHS Compliant	Lead Free				TO-220		44.45mm	0.490 12.44mm		Board Level, Vertical				6.30°C/W	1.750 44.45mm	Bolt On and Board Mounts	TO-218, TO-247	1.50°C/W @ 400 LFM	Black Anodized	4.0W @ 30°C
574602B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	10.03mm		0.690 17.53mm	RoHS Compliant	Lead Free				TO-220		17.53mm	0.860 21.84mm		Board Level				21.60°C/W	0.395 10.03mm	Clip	TO-220	6.00°C/W @ 600 LFM	Black Anodized	3.0W @ 60°C
6000DG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Solder	Copper			2007		Active	Not Applicable				25.4mm	RoHS Compliant		Tin			Axial		6.35mm	25.4mm		Passive
578305B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Press Fit	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black		0.316 8.03mm ID	0.750 19.05mm	RoHS Compliant	Lead Free				TO-5		12.7mm	0.830 21.08mm		Top Mount				35.00°C/W	0.395 10.03mm	Press Fit	TO-5	20.00°C/W @ 300 LFM	Black Anodized	1.0W @ 30°C
566902B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Clip	Aluminum	Rectangular, Fins		2007		Active	Not Applicable				0.850 21.59mm	RoHS Compliant					TO-220			1.000 25.40mm		Board Level				18.80°C/W	0.500 12.70mm	Clip	TO-220, TO-262	9.00°C/W @ 200 LFM	Black Anodized	2.0W @ 40°C
342942	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	6 Weeks	Push Pin	Copper	Square, Fins				Active	Not Applicable				1.732 44.00mm	RoHS Compliant								1.772 45.00mm		Top Mount				8.00°C/W	0.886 22.50mm	Push Pin	BGA	1.65°C/W @ 200 LFM	AavSHIELD 3C
6045B	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Clip	Aluminum	Rectangular				Active	Not Applicable	Black			1.000 25.40mm	Non-RoHS Compliant	Lead Free				TO-220		8.89mm	0.750 19.05mm		Board Level				26.00°C/W	0.350 8.89mm	Clip	TO-220	16.00°C/W @ 200 LFM	Black Anodized	1.0W @ 30°C
