Switches

Switches are electrical components used to open or close circuits, thereby controlling the flow of current or signals. They provide a means to selectively connect or disconnect electrical pathways. Switches come in various types, including mechanical switches, such as push-buttons and toggle switches, and solid-state switches, such as transistors and relays. They are essential in electronic systems for user input, control functions, and signal routing. Switches can be found in everyday devices like keyboards, power controls, and circuit breakers.

Name	Manufacturer	Quantity	Datasheet	Published	Series	Part Status	Moisture Sensitivity Level (MSL)	Contact Material	Mfr	Mounting Type	Operating Temperature	Ingress Protection	Termination Style	Current Rating (Amps)	Electrical Life	Switch Function	Contact Finish	Actuator Type	Actuator Orientation	Outline	Contact Rating @ Voltage	Mechanical Life	Circuit	Actuator Length	Illumination	Actuator Material	Contact Timing	Operating Force	Illumination Voltage (Nominal)	Illumination Type, Color	Switch Travel	Actuator Height off PCB, Vertical	Actuator Length, Right Angle	Features	Voltage Rating - DC
TS06-667-43-BK-160-G-SMT-TR	CUI Devices	RFQ Min: 1 Mult: 1			TS06				CUI Devices	Surface Mount	-30°C ~ 80°C	-	Gull Wing			Off-Mom		Standard	Top Actuated	6.70mm x 6.00mm	0.05A @ 12VDC	80,000 Cycles	SPST-NO		Non-Illuminated	Polyamide (PA FR52), Nylon FR52		160gf	-	-	0.25mm	4.30mm	-	-
TS14-1212-60-BK-260-SCR-D	CUI Devices	RFQ Min: 1 Mult: 1			TS14				CUI Devices	Through Hole	-30°C ~ 80°C	-	PC Pin			Off-Mom		Standard	Top Actuated	12.00mm x 12.00mm	0.05A @ 12VDC	60,000 Cycles	SPST-NO		Non-Illuminated	Polyamide (PA66), Nylon 6/6		260gf	-	-	0.35mm	6.00mm	-	-
TS13-1212-73-BK-260-D	CUI Devices	RFQ Min: 1 Mult: 1			TS13				CUI Devices	Through Hole	-30°C ~ 80°C	-	PC Pin			Off-Mom		Plunger for Cap	Top Actuated	12.00mm x 12.00mm	0.05A @ 12VDC	60,000 Cycles	SPST-NO		Non-Illuminated	Polyamide (PA66), Nylon 6/6		260gf	-	-	0.35mm	7.30mm	-	-
TS02-66-60-BK-260-SCR-D	CUI Devices	RFQ Min: 1 Mult: 1			TS02				CUI Devices	Through Hole	-30°C ~ 80°C	-	PC Pin			Off-Mom		Standard	Top Actuated	6.00mm x 6.00mm	0.05A @ 12VDC	60,000 Cycles	SPST-NO		Non-Illuminated	Polyamide (PA66), Nylon 6/6		260gf	-	-	0.25mm	6.00mm	-	-
TS14-1212-70-BK-100-SCR-D	CUI Devices	RFQ Min: 1 Mult: 1			TS14				CUI Devices	Through Hole	-30°C ~ 80°C	-	PC Pin			Off-Mom		Standard	Top Actuated	12.00mm x 12.00mm	0.05A @ 12VDC	100,000 Cycles	SPST-NO		Non-Illuminated	Polyamide (PA66), Nylon 6/6		100gf	-	-	0.35mm	7.00mm	-	-
TS02-66-160-BK-160-LCR-D	CUI Devices	RFQ Min: 1 Mult: 1			TS02				CUI Devices	Through Hole	-30°C ~ 80°C	-	PC Pin			Off-Mom		Standard	Top Actuated	6.00mm x 6.00mm	0.05A @ 12VDC	80,000 Cycles	SPST-NO		Non-Illuminated	Polyamide (PA66), Nylon 6/6		160gf	-	-	0.25mm	16.00mm	-	-
TS04-66-73-BK-160-SMT	CUI Devices	RFQ Min: 1 Mult: 1							CUI Devices	Surface Mount	-30°C ~ 80°C	-	Gull Wing			Off-Mom		Standard	Top Actuated	6.00mm x 6.00mm	0.05A @ 12VDC	80,000 Cycles	SPST-NO		Non-Illuminated	Polyamide (PA66), Nylon 6/6		160gf	-	-	0.25mm	7.30mm	-	-
TS02-66-95-BK-100-SCR-D	CUI Devices	RFQ Min: 1 Mult: 1			TS02				CUI Devices	Through Hole	-30°C ~ 80°C	-	PC Pin			Off-Mom		Standard	Top Actuated	6.00mm x 6.00mm	0.05A @ 12VDC	100,000 Cycles	SPST-NO		Non-Illuminated	Polyamide (PA66), Nylon 6/6		100gf	-	-	0.25mm	9.50mm	-	-
TS14-1212-120-BK-260-SCR-D	CUI Devices	RFQ Min: 1 Mult: 1			TS14				CUI Devices	Through Hole	-30°C ~ 80°C	-	PC Pin			Off-Mom		Standard	Top Actuated	12.00mm x 12.00mm	0.05A @ 12VDC	60,000 Cycles	SPST-NO		Non-Illuminated	Polyamide (PA66), Nylon 6/6		260gf	-	-	0.35mm	12.00mm	-	-
TS05-66-43-BK-260-SMT-67	CUI Devices	RFQ Min: 1 Mult: 1			TS05				CUI Devices	Surface Mount	-30°C ~ 80°C	IP67 - Dust Tight, Waterproof	Gull Wing			Off-Mom		Standard	Top Actuated	6.10mm x 6.10mm	0.05A @ 12VDC	60,000 Cycles	SPST-NO		Non-Illuminated	Polyamide (PA6T), Nylon 6T		260gf	-	-	0.25mm	4.30mm	-	-
TS02-66-73-BK-160-SCR-D	CUI Devices	RFQ Min: 1 Mult: 1							CUI Devices	Through Hole	-30°C ~ 80°C	-	PC Pin			Off-Mom		Standard	Top Actuated	6.00mm x 6.00mm	0.05A @ 12VDC	80,000 Cycles	SPST-NO		Non-Illuminated	Polyamide (PA66), Nylon 6/6		160gf	-	-	0.25mm	7.30mm	-	-
TS02-66-80-BK-260-SCR-D	CUI Devices	RFQ Min: 1 Mult: 1			TS02				CUI Devices	Through Hole	-30°C ~ 80°C	-	PC Pin			Off-Mom		Standard	Top Actuated	6.00mm x 6.00mm	0.05A @ 12VDC	60,000 Cycles	SPST-NO		Non-Illuminated	Polyamide (PA66), Nylon 6/6		260gf	-	-	0.25mm	8.00mm	-	-
MSS-102564-D	CUI Devices	RFQ Min: 1 Mult: 1			-			Nickel	CUI Devices	Through Hole	-40°C ~ 85°C		PC Pin	300mA (DC)	2,000 Cycles	On-On	Gold	Flush				10,000 Cycles	SPDT	Flush		Polyamide (PA66), Nylon 6/6	Not Specified	250gf			1.60mm			-	24 V
TS17-48-05-YE-260-SMT-TR	CUI Devices	RFQ Min: 1 Mult: 1			TS17				CUI Devices	Surface Mount	-30°C ~ 80°C	-	J Lead			Off-Mom		Flush	Top Actuated	4.80mm x 4.80mm	0.05A @ 12VDC	40,000 Cycles	SPST-NO		Non-Illuminated	-		260gf	-	-	0.20mm	0.55mm	-	-
TS03-66-80-BK-260-LCR-D-67	CUI Devices	RFQ Min: 1 Mult: 1							CUI Devices	Through Hole	-30°C ~ 80°C	IP67 - Dust Tight, Waterproof	PC Pin			Off-Mom		Standard	Top Actuated	6.10mm x 6.10mm	0.05A @ 12VDC	60,000 Cycles	SPST-NO		Non-Illuminated	Polyamide (PA66), Nylon 6/6		260gf	-	-	0.25mm	8.00mm	-	-
TS14-1212-100-BK-260-SCR-D	CUI Devices	RFQ Min: 1 Mult: 1			TS14				CUI Devices	Through Hole	-30°C ~ 80°C	-	PC Pin			Off-Mom		Standard	Top Actuated	12.00mm x 12.00mm	0.05A @ 12VDC	60,000 Cycles	SPST-NO		Non-Illuminated	Polyamide (PA66), Nylon 6/6		260gf	-	-	0.35mm	10.00mm	-	-
TS06-667-55-WT-160-G-SMT-TR	CUI Devices	RFQ Min: 1 Mult: 1			TS06				CUI Devices	Surface Mount	-30°C ~ 80°C	-	Gull Wing			Off-Mom		Standard	Top Actuated	6.70mm x 6.00mm	0.05A @ 12VDC	80,000 Cycles	SPST-NO		Non-Illuminated	Polyamide (PA FR52), Nylon FR52		160gf	-	-	0.25mm	5.50mm	-	-
TS07-667-37-BK-100-SMT-TR	CUI Devices	RFQ Min: 1 Mult: 1			TS07				CUI Devices	Surface Mount	-30°C ~ 80°C	-	Gull Wing			Off-Mom		Standard	Top Actuated	6.10mm x 6.10mm	0.05A @ 12VDC	100,000 Cycles	SPST-NO		Non-Illuminated	Polyamide (PA FR52), Nylon FR52		100gf	-	-	0.25mm	3.70mm	-	-
TS14-1212-43-BK-100-SCR-D	CUI Devices	RFQ Min: 1 Mult: 1			TS14				CUI Devices	Through Hole	-30°C ~ 80°C	-	PC Pin			Off-Mom		Standard	Top Actuated	12.00mm x 12.00mm	0.05A @ 12VDC	100,000 Cycles	SPST-NO		Non-Illuminated	Polyamide (PA66), Nylon 6/6		100gf	-	-	0.35mm	4.30mm	-	-
TS02-66-150-BK-260-LCR-D	CUI Devices	RFQ Min: 1 Mult: 1			TS02				CUI Devices	Through Hole	-30°C ~ 80°C	-	PC Pin			Off-Mom		Standard	Top Actuated	6.00mm x 6.00mm	0.05A @ 12VDC	60,000 Cycles	SPST-NO		Non-Illuminated	Polyamide (PA66), Nylon 6/6		260gf	-	-	0.25mm	15.00mm	-	-
CUI-4138-6FT	CUI Devices	RFQ Min: 1 Mult: 1	download	2007		Obsolete	1 (Unlimited)
TS06-667-25-BK-160-G-SMT-TR	CUI Devices	RFQ Min: 1 Mult: 1			TS06				CUI Devices	Surface Mount	-30°C ~ 80°C	-	Gull Wing			Off-Mom		Standard	Top Actuated	6.70mm x 6.00mm	0.05A @ 12VDC	80,000 Cycles	SPST-NO		Non-Illuminated	Polyamide (PA FR52), Nylon FR52		160gf	-	-	0.25mm	2.50mm	-	-
TS12-74-60-BK-250-SMT-TR	CUI Devices	RFQ Min: 1 Mult: 1			TS12				CUI Devices	Surface Mount	-30°C ~ 80°C	-	J Lead			Off-Mom		Plunger for Cap	Top Actuated	7.40mm x 7.40mm	0.05A @ 12VDC	50,000 Cycles	SPST-NO		Non-Illuminated	Polyphthalamide (PPA)		250gf	-	-	0.25mm	6.00mm	-	-
TS11-674-65-BK-100-RA-D	CUI Devices	RFQ Min: 1 Mult: 1			TS11				CUI Devices	Through Hole, Right Angle	-30°C ~ 80°C	-	PC Pin			Off-Mom		Standard	Side Actuated	-	0.05A @ 12VDC	100,000 Cycles	SPST-NO		Non-Illuminated	Polyamide (PA66), Nylon 6/6		100gf	-	-	0.25mm	-	6.50mm	-
TS06-667-30-R-260-G-SMT-TR	CUI Devices	RFQ Min: 1 Mult: 1			TS06				CUI Devices	Surface Mount	-30°C ~ 80°C	-	Gull Wing			Off-Mom		Standard	Top Actuated	6.70mm x 6.00mm	0.05A @ 12VDC	60,000 Cycles	SPST-NO		Non-Illuminated	Polyamide (PA FR52), Nylon FR52		260gf	-	-	0.25mm	3.00mm	-	-
TS06-667-25-BK-100-G-SMT-TR	CUI Devices	RFQ Min: 1 Mult: 1			TS06				CUI Devices	Surface Mount	-30°C ~ 80°C	-	Gull Wing			Off-Mom		Standard	Top Actuated	6.70mm x 6.00mm	0.05A @ 12VDC	100,000 Cycles	SPST-NO		Non-Illuminated	Polyamide (PA FR52), Nylon FR52		100gf	-	-	0.25mm	2.50mm	-	-
