UCC27201DG4 Overview
The SOIC package offers greater flexibility.Gate drivers is package in Rail/Tube case.Its configuration starts with 8 terminations.Mounting the device requires Surface Mount.When the device is designed, it has 8 pins.The device is specifically designed to operate at 12V volts.Mosfet driver is equipped wMosfet driverh an interface chip HALF BRIDGE BASED PERIPHERAL DRIVER.In the maximum case, the output current can be limited to 3A.There are several useful electronic components in this subcategory of MOSFET Drivers.On the board, there are 8 component pins.The basis of the model has 2 outputs integrated.There is a maximum value of 140°C for the allowable operating temperature.Operating temperatures can be as low as -40°C.To ensure high stability, the supply current should be kept at 5.5mA.The maximum voltage for operation is 17V.This device is designed to operate with a voltage of 8V.Mosfet gate drivers outputs a current of 3A at the moment.Mosfet gate drivers is recommended that the operating supply voltage be set to 12V.A frequency of 1MHz can improve efficiency.
UCC27201DG4 Features
Embedded in the Rail/Tube package
8 pins
UCC27201DG4 Applications
There are a lot of Texas Instruments UCC27201DG4 gate drivers applications.
- Industrial Motor Inverter - Power Tools, Robotics
- High current laser/LED systems
- Isolated Supplies for controller area network (CAN),
- Isolated Supplies for Motor Control
- Pulse transformer drivers
- DC/DC converters
- Motor controllers
- A/D drivers
- Commercial air-conditioning (CAC)
- Power factor correction (PFC) circuits
