TPS63020DSJR
TPS63020DSJR
815-TPS63020DSJR
14-VFDFN Exposed Pad
14 Terminals 1.8V 14-Pin TPS63020 DC DC Voltage Regulator SWITCHING REGULATOR 1 Outputs 2.4MHz Tape & Reel (TR) 3.5A Switch 14-VFDFN Exposed Pad
In Stock : 999
Share
Please send RFQ, we will respond immediately.
Product Details
Purchasing and Inquiry
TPS63020DSJR Description
The TPS63020 devices provide a power supply solution for products powered by either a two-cell or three-cell alkaline, NiCd or NiMH battery, a one-cell Li-ion or Li-polymer battery, supercapacitors or other supply rails. Output currents up to 3 A are supported. When using batteries, they can be discharged down to below 2 V. The buck-boost converter is based on a fixed frequency, pulse width modulation (PWM) controller using synchronous rectification to obtain maximum efficiency. At low load currents, the converter enters power save mode to maintain high efficiency over a wide load current range. The power save mode can be disabled, forcing the converter to operate at a fixed switching frequency. The maximum average current in the switches is limited to a typical value of 4 A. The output voltage is programmable using an external resistor divider, or is fixed internally on the chip. The converter can be disabled to minimize battery drain. During shutdown, the load is disconnected from the battery.
TPS63020DSJR Features
Input voltage range: 1.8 V to 5.5 V
Adjustable output voltage: 1.2 V to 5.5 V
Output current for VIN > 2.5 V, VOUT = 3.3 V: 2 A
High efficiency over the entire load range
Average current mode buck-boost architecture
Power good output
Safety and robust operation features
ROHS3 Compliant
No SVHC
Lead Free
TPS63020DSJR Applications
Pre-regulation in battery-powered devices: EPOS (portable data terminal, barcode scanner), ecigarette, single board computer, IP network camera, video doorbell, land mobile radios
Voltage stabilizer: wired communication, wireless communication, PLC, optical module
Backup supercapacitor supply: electricity meter, solid state drive (SSD) - enterprise
5G Communication
Electrification of automobile
Industrial 4.0
