Heat Sinks

Name	Manufacturer	Quantity	Datasheet	Factory Lead Time	Mount	Material	Shape	Packaging	Published	Series	Part Status	Moisture Sensitivity Level (MSL)	Color	Depth	Diameter	Length	RoHS Status	Lead Free	Contact Plating	Radiation Hardening	Number of Pins	Package / Case	REACH SVHC	Height	Width	Weight	Manufacturer Package Identifier	Type	Body Material	Power Dissipation	Natural Thermal Resistance	Thermal Resistance @ Natural	Height Off Base (Height of Fin)	Attachment Method	Package Cooled	Thermal Resistance @ Forced Air Flow	Material Finish	Power Dissipation @ Temperature Rise
591302B02800G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PCB, Through Hole	Aluminum	Rectangular, Fins	Bulk	2007		Active	Not Applicable	Black	12.7mm		0.750 19.05mm	RoHS Compliant	Lead Free		No		TO-220	No SVHC	19.05mm	0.500 12.70mm			Board Level, Vertical				26.80°C/W	0.500 12.70mm	Clip and Board Locks	TO-220, TO-262	7.00°C/W @ 400 LFM	Black Anodized	1.0W @ 30°C
501000B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Adhesive	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			0.750 19.05mm	RoHS Compliant	Lead Free			14			5.39mm	0.604 15.34mm			Top Mount				60.00°C/W	0.212 5.39mm	Thermal Tape, Adhesive (Not Included)	14-DIP and 16-DIP	60.00°C/W @ 100 LFM	Black Anodized	0.6W @ 40°C
607602F00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Pin Fins		2016		Active	Not Applicable				48.000 1219.20mm	RoHS Compliant								3.250 82.55mm			Top Mount, Extrusion					1.000 25.40mm	Adhesive				4.0W @ 20°C
647058	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1					Rectangular, Fins				Active	Not Applicable				4.252 108.00mm	RoHS Compliant								3.071 78.00mm			Top Mount					0.992 25.20mm	Bolt On	Intel® Xeon® CPU
573300D00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Surface Mount	Aluminum	Rectangular, Fins	Box	2007		Active	Not Applicable		12.7mm		0.500 12.70mm	RoHS Compliant	Lead Free	Tin	No		TO-263	No SVHC	10.16mm	1.030 26.16mm			Top Mount				18.00°C/W	0.400 10.16mm	SMD Pad	TO-263 (D2Pak)	8.00°C/W @ 300 LFM	Tin	1.3W @ 30°C
576802B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, Plug-In	Aluminum	Rectangular, Fins	Bulk	2003		Active	Not Applicable	Black	12.7mm		0.750 19.05mm	RoHS Compliant	Lead Free		No		TO-220	No SVHC	12.7mm	0.500 12.70mm			Board Level				27.30°C/W	0.500 12.70mm	Clip	TO-220, TO-262	7.00°C/W @ 400 LFM	Black Anodized	1.5W @ 40°C
342949	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	6 Weeks	Push Pin	Copper	Square, Fins				Active	Not Applicable				3.150 80.00mm	RoHS Compliant								3.150 80.00mm			Top Mount				5.10°C/W	0.472 12.00mm	Push Pin	BGA	1.20°C/W @ 200 LFM	AavSHIELD 3C
577404B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rectangular, Fins	Bulk	2007		Active	Not Applicable	Black	13.21mm		0.750 19.05mm	RoHS Compliant	Lead Free		No		TO-202	No SVHC	12.7mm	0.520 13.21mm	113.398093g		Board Level				24.00°C/W	0.500 12.70mm	Bolt On	TO-202	10.00°C/W @ 200 LFM	Black Anodized	2.0W @ 50°C
342946	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	6 Weeks	Push Pin	Copper	Square, Fins				Active	Not Applicable				2.362 60.00mm	RoHS Compliant								2.362 60.00mm			Top Mount				7.20°C/W	0.866 22.00mm	Push Pin	BGA	0.80°C/W @ 300 LFM	AavSHIELD 3C
576802B04000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin, Solder	Aluminum	Rectangular, Fins	Bulk	2007		Active	Not Applicable	Black	12.7mm		0.750 19.05mm	RoHS Compliant	Lead Free		No		TO-220	No SVHC	12.7mm	0.500 12.70mm			Board Level, Vertical				27.30°C/W	0.500 12.70mm	Clip and PC Pin	TO-220, TO-262	7.00°C/W @ 400 LFM	Black Anodized	1.0W @ 30°C
7130DG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Clip, PC Pin	Copper	Rectangular, Fins		2007		Active	Not Applicable		15.49mm		1.025 26.04mm	RoHS Compliant	Lead Free				TO-218		15.49mm	1.005 25.53mm			Board Level, Vertical	Copper			23.10°C/W	0.610 15.49mm	Clip and PC Pin	TO-218	4.00°C/W @ 500 LFM	Tin	0.5W @ 20°C
M48098B011000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Angled Fins			Max Clip System™	Active	Not Applicable				0.980 24.89mm									0.866 22.00mm			Board Level, Vertical					1.516 38.50mm	Clip and PC Pin	TO-126, TO-220, TO-247		Black Anodized
550302B00000	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Bolt, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			1.670 42.42mm	Non-RoHS Compliant					TO-220		42.42mm	1.000 25.40mm			Board Level, Vertical				11.20°C/W	1.000 25.40mm	Bolt On and PC Pin	TO-220	4.00°C/W @ 300 LFM	Black Anodized	4.0W @ 40°C
575603B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rhombus		2007		Active	Not Applicable	Black	32.77mm		1.630 41.40mm	RoHS Compliant					TO-3		12.7mm	1.290 32.77mm			Board Level				15.60°C/W	0.500 12.70mm	Bolt On	TO-3	3.00°C/W @ 600 LFM	Black Anodized	3.0W @ 50°C
533102B02551G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			1.500 38.10mm	RoHS Compliant					Radial		38.1mm	1.375 34.93mm			Board Level, Vertical				11.00°C/W	0.500 12.70mm	Clip and PC Pin	TO-220	3.00°C/W @ 500 LFM	Black Anodized	8.0W @ 80°C
631352F00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Pin Fins		2016		Active	Not Applicable				48.000 1219.20mm	RoHS Compliant								2.125 53.98mm			Top Mount, Extrusion					1.750 44.45mm	Adhesive		1.50°C/W @ 200 LFM
508600B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Adhesive	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			1.450 36.83mm	RoHS Compliant							4.83mm	0.530 13.46mm			Top Mount				32.00°C/W	0.190 4.83mm	Thermal Tape, Adhesive (Not Included)	28-DIP	10.00°C/W @ 700 LFM	Black Anodized	2.5W @ 80°C
507002B05300G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin	Aluminum	Rectangular, Fins		2007	Hat Section 5070	Active	Not Applicable				0.700 17.78mm	RoHS Compliant	Lead Free				TO-220			1.750 44.45mm			Board Level, Vertical				15.60°C/W	0.375 9.52mm	Bolt On and PC Pin	TO-220	5.00°C/W @ 500 LFM	Black Anodized	2.0W @ 40°C
6025DG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Through Hole	Anodized, Copper			2006		Active	Not Applicable		6.34mm		6.34mm	RoHS Compliant	Lead Free		No		TO-220	No SVHC	32mm	22.22mm			Passive	Copper		17.9 °C/W
573902B03900G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			1.500 38.10mm	RoHS Compliant					TO-220		38.1mm	0.500 12.70mm			Board Level, Vertical				18.80°C/W	0.500 12.70mm	Clip and PC Pin	TO-220	7.00°C/W @ 200 LFM	Black Anodized	3.0W @ 60°C
657152F00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Pin Fins		2016		Active	Not Applicable				48.000 1219.20mm	RoHS Compliant								0.985 25.00mm			Top Mount, Extrusion					0.390 9.91mm	Adhesive
322605B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Press Fit	Aluminum	Cylindrical	Bulk	2007		Active	Not Applicable	Black		0.315 8.00mm ID 0.750 19.05mm OD	19.05mm	RoHS Compliant	Lead Free		No		TO-5	No SVHC	6mm				Top Mount		1.25W		54.00°C/W	0.250 6.35mm	Press Fit	TO-5	25.00°C/W @ 200 LFM	Black Anodized	1.0W @ 60°C
529801B02500G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins	Bulk	2001		Active	Not Applicable	Black	25.4mm		1.500 38.10mm	RoHS Compliant	Lead Free		No		Radial	No SVHC	38mm	1.650 41.91mm		529801b02500g	Board Level, Vertical				5.00°C/W	1.000 25.40mm	Bolt On and PC Pin	TO-218	2.00°C/W @ 500 LFM	Black Anodized	10.0W @ 50°C
574802B03700G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Clip, PC Pin, Solder	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	10.67mm		0.900 22.86mm	RoHS Compliant					TO-220		22.86mm	1.020 25.91mm			Board Level, Vertical				20.40°C/W	0.420 10.67mm	Clip and PC Pin	TO-220	6.00°C/W @ 500 LFM	Black Anodized	3.0W @ 60°C
573300D00010G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	PCB, Surface Mount	Aluminum	Rectangular, Fins	Tape & Reel (TR)	2007		Active	Not Applicable		12.7mm		0.500 12.70mm	RoHS Compliant	Lead Free		No		TO-263	No SVHC	10.16mm	1.030 26.16mm			Top Mount				18.00°C/W	0.400 10.16mm	SMD Pad	TO-263 (D2Pak)	10.00°C/W @ 200 LFM	Tin	1.3W @ 30°C
576802B03700G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins	Bulk	2005		Active	Not Applicable	Black	12.7mm		0.748 19.00mm	RoHS Compliant	Lead Free		No		TO-220	No SVHC	19mm	0.500 12.70mm			Board Level				27.30°C/W	0.500 12.70mm	Clip and PC Pin	TO-220, TO-262	7.00°C/W @ 400 LFM	Black Anodized	1.0W @ 30°C
533502B02552G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			1.650 41.91mm	RoHS Compliant					TO-220		50.8mm	1.000 25.40mm			Board Level, Vertical				4.50°C/W	2.000 50.80mm	Clip and PC Pin	TO-220	1.00°C/W @ 800 LFM	Black Anodized	6.0W @ 30°C
782653B01000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	8 Weeks					2007		Active	Not Applicable					RoHS Compliant					TO-220
7178DG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Bolt, PC Pin, Screw	Copper	Rectangular, Fins		2007		Active	Not Applicable		9.52mm		0.750 19.05mm	RoHS Compliant	Lead Free				TO-220		19.05mm	0.520 13.21mm			Board Level, Vertical	Copper			35.70°C/W	0.375 9.52mm	Bolt On and PC Pin	TO-220	5.00°C/W @ 700 LFM	Tin	0.6W @ 30°C
513201B02500G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins	Bulk	2007		Active	Not Applicable	Black	12.7mm		2.000 50.80mm	RoHS Compliant	Lead Free				Radial		12.7mm	1.375 34.93mm			Board Level, Vertical				8.30°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-218, TO-247	3.00°C/W @ 400 LFM	Black Anodized	2.0W @ 20°C
