Heat Sinks

Name	Manufacturer	Quantity	Datasheet	Factory Lead Time	Mount	Material	Shape	Packaging	Published	Series	Part Status	Moisture Sensitivity Level (MSL)	Color	Depth	Diameter	Length	RoHS Status	Lead Free	Contact Plating	Radiation Hardening	Number of Pins	Package / Case	REACH SVHC	Height	Width	Weight	Manufacturer Package Identifier	Type	Body Material	Body Plating	Power Dissipation	Thermal Resistance @ Natural	Height Off Base (Height of Fin)	Attachment Method	Package Cooled	Thermal Resistance @ Forced Air Flow	Material Finish	Power Dissipation @ Temperature Rise
577202B04000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	12.7mm		0.750 19.05mm	RoHS Compliant	Lead Free		No		TO-220		19.05mm	0.520 13.21mm	113.398093g		Board Level, Vertical				24.40°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220	10.00°C/W @ 200 LFM	Black Anodized	1.5W @ 40°C
374424B00035G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	8 Weeks	Adhesive	Aluminum	Square, Pin Fins		2002		Active	Not Applicable	Black	27mm		1.063 27.00mm	RoHS Compliant	Lead Free				BGA	No SVHC	18mm	1.063 27.00mm			Top Mount	Plastic			20.30°C/W	0.709 18.00mm	Thermal Tape, Adhesive (Included)	BGA	6.50°C/W @ 200 LFM	Black Anodized	4.0W @ 80°C
7025BG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Bolt, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	24.13mm		1.130 28.70mm	RoHS Compliant	Lead Free				TO-220		28.7mm	1.900 48.26mm			Board Level, Vertical				6.80°C/W	0.950 24.13mm	Bolt On and PC Pin	TO-220	4.00°C/W @ 300 LFM	Black Anodized	6.0W @ 50°C
322505B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Press Fit	Aluminum	Cylindrical	Bulk	2007		Active	Not Applicable	Black	19.05mm	0.315 8.00mm ID 0.750 19.05mm OD	19.05mm	RoHS Compliant	Lead Free	Tin	No		TO-5	Unknown	10.16mm	19.05mm			Top Mount				56.00°C/W	0.400 10.16mm	Press Fit	TO-5	15.00°C/W @ 400 LFM	Black Anodized	0.5W @ 30°C
563202B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			2.000 50.80mm	RoHS Compliant					TO-220		55.55mm	1.380 35.05mm			Board Level				9.40°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220	5.00°C/W @ 200 LFM	Black Anodized	1.0W @ 20°C
508600B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Adhesive	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			1.450 36.83mm	RoHS Compliant							4.83mm	0.530 13.46mm			Top Mount				32.00°C/W	0.190 4.83mm	Thermal Tape, Adhesive (Not Included)	28-DIP	10.00°C/W @ 700 LFM	Black Anodized	2.5W @ 80°C
321527B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Threaded Coupling, Vertical	Aluminum	Cylindrical		2007		Active	Not Applicable	Black		0.750 19.05mm OD	19.05mm	RoHS Compliant	Lead Free				TO-5	No SVHC	5.33mm	5.33mm			Top Mount		Anodized	2W	35.20°C/W	0.290 7.37mm	Threaded Coupling	TO-5, TO-39	20.00°C/W @ 300 LFM	Black Anodized	0.5W @ 20°C
513302B02500G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins	Box	2007		Active	Not Applicable		12.7mm		2.500 63.50mm	RoHS Compliant	Lead Free				TO-220			1.375 34.93mm			Board Level, Vertical				8.00°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220	4.00°C/W @ 200 LFM	Black Anodized	8.0W @ 60°C
576802B03700G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins	Bulk	2005		Active	Not Applicable	Black	12.7mm		0.748 19.00mm	RoHS Compliant	Lead Free		No		TO-220	No SVHC	19mm	0.500 12.70mm			Board Level				27.30°C/W	0.500 12.70mm	Clip and PC Pin	TO-220, TO-262	7.00°C/W @ 400 LFM	Black Anodized	1.0W @ 30°C
780802F00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Pin Fins		2016		Active	Not Applicable				49.500 1257.30mm	RoHS Compliant								1.063 27.00mm			Board Level, Vertical, Extrusion					2.362 60.00mm	PC Pin
533002B02551G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins	Box	2007		Active	Not Applicable	Black	12.7mm		1.000 25.40mm	RoHS Compliant	Lead Free				TO-220		25.4mm	1.375 34.93mm			Board Level, Vertical				13.00°C/W	0.500 12.70mm	Clip and PC Pin	TO-220	4.00°C/W @ 400 LFM	Black Anodized	2.0W @ 30°C
507002B05300G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin	Aluminum	Rectangular, Fins		2007	Hat Section 5070	Active	Not Applicable				0.700 17.78mm	RoHS Compliant	Lead Free				TO-220			1.750 44.45mm			Board Level, Vertical				15.60°C/W	0.375 9.52mm	Bolt On and PC Pin	TO-220	5.00°C/W @ 500 LFM	Black Anodized	2.0W @ 40°C
530614B05300G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Solder				2007		Active	Not Applicable	Black			12.7mm	RoHS Compliant	Lead Free	Tin			TO-220		29.97mm	25.41mm			Passive
701652F00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Fins		2016		Active	Not Applicable				48.000 1219.20mm	RoHS Compliant								12.000 304.80mm			Top Mount, Extrusion					1.780 45.21mm	Adhesive		0.20°C/W @ 700 LFM
6239BG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Clip	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			1.159 29.44mm	RoHS Compliant					TO-220		29.44mm	1.005 25.53mm			Board Level, Vertical				13.60°C/W	0.610 15.49mm	Clip	TO-220	6.00°C/W @ 600 LFM	Black Anodized	2.0W @ 40°C
782653B01000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	8 Weeks					2007		Active	Not Applicable					RoHS Compliant					TO-220
321127B00000	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Threaded Coupling	Aluminum	Cylindrical		2007		Active	Not Applicable	Black		0.625 15.88mm OD		Non-RoHS Compliant	Lead Free	Lead, Tin			TO-5		6.88mm				Top Mount				54.00°C/W		Threaded Coupling	TO-5	25.00°C/W @ 200 LFM	Black Anodized	1.4W @ 70°C
6238BG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			1.159 29.44mm	RoHS Compliant					TO-220		29.44mm	1.005 25.53mm			Board Level, Vertical				13.60°C/W	0.610 15.49mm	Clip	TO-220	6.00°C/W @ 600 LFM	Black Anodized	2.0W @ 40°C
M47098B011000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Angled Fins			Max Clip System™	Active	Not Applicable				0.980 24.89mm									0.764 19.40mm			Board Level, Vertical					1.240 31.50mm	Clip and PC Pin	TO-126, TO-220, TO-247		Black Anodized
578902B03200G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	17.53mm		0.690 17.53mm	RoHS Compliant	Lead Free		No		TO-220		17.53mm	0.860 21.84mm			Board Level				21.60°C/W	0.395 10.03mm	Clip and PC Pin	TO-220	12.00°C/W @ 200 LFM	Black Anodized	3.0W @ 60°C
6396BG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Screw	Aluminum	Rectangular, Fins	Box	2007		Active	1 (Unlimited)	Black	25.4mm		1.000 25.40mm	RoHS Compliant	Lead Free		No	220	Radial	No SVHC	25.4mm	1.650 41.91mm			Board Level, Vertical				5.60°C/W	1.000 25.40mm	Bolt On and PC Pin	TO-220, TO-218	1.50°C/W @ 600 LFM	Black Anodized	4.0W @ 30°C
576802B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, Plug-In	Aluminum	Rectangular, Fins	Bulk	2003		Active	Not Applicable	Black	12.7mm		0.750 19.05mm	RoHS Compliant	Lead Free		No		TO-220	No SVHC	12.7mm	0.500 12.70mm			Board Level				27.30°C/W	0.500 12.70mm	Clip	TO-220, TO-262	7.00°C/W @ 400 LFM	Black Anodized	1.5W @ 40°C
581202B02500G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins	Bulk	2007		Active	Not Applicable	Black	16.26mm		2.000 50.80mm	RoHS Compliant	Lead Free				TO-220	No SVHC	50.8mm	0.640 16.26mm	113.398093g		Board Level, Vertical				12.80°C/W	0.640 16.26mm	Bolt On and PC Pin	TO-220	4.00°C/W @ 300 LFM	Black Anodized	1.5W @ 20°C
529801B02500G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins	Bulk	2001		Active	Not Applicable	Black	25.4mm		1.500 38.10mm	RoHS Compliant	Lead Free		No		Radial	No SVHC	38mm	1.650 41.91mm		529801b02500g	Board Level, Vertical				5.00°C/W	1.000 25.40mm	Bolt On and PC Pin	TO-218	2.00°C/W @ 500 LFM	Black Anodized	10.0W @ 50°C
575400B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Press Fit	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			0.602 15.29mm	RoHS Compliant					TO-92		30.98mm	15.29mm			Top Mount				40.00°C/W	1.220 31.00mm	Press Fit	TO-92	20.00°C/W @ 200 LFM	Black Anodized	0.5W @ 20°C
647058	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1					Rectangular, Fins				Active	Not Applicable				4.252 108.00mm	RoHS Compliant								3.071 78.00mm			Top Mount					0.992 25.20mm	Bolt On	Intel® Xeon® CPU
335714B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks					2007		Active	Not Applicable				30.15mm	RoHS Compliant					BGA						Passive
533102B02551G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			1.500 38.10mm	RoHS Compliant					Radial		38.1mm	1.375 34.93mm			Board Level, Vertical				11.00°C/W	0.500 12.70mm	Clip and PC Pin	TO-220	3.00°C/W @ 500 LFM	Black Anodized	8.0W @ 80°C
581101B02500G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Solder			Bulk	2007		Active	Not Applicable				16.26mm	RoHS Compliant					TO-218						Passive
501000B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Adhesive	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			0.750 19.05mm	RoHS Compliant	Lead Free			14			5.39mm	0.604 15.34mm			Top Mount				60.00°C/W	0.212 5.39mm	Thermal Tape, Adhesive (Not Included)	14-DIP and 16-DIP	60.00°C/W @ 100 LFM	Black Anodized	0.6W @ 40°C
