Heat Sinks

Name	Manufacturer	Quantity	Datasheet	Factory Lead Time	Mount	Material	Shape	Packaging	Published	Part Status	Moisture Sensitivity Level (MSL)	Color	Depth	Diameter	Length	RoHS Status	Lead Free	Contact Plating	Radiation Hardening	Number of Pins	Package / Case	REACH SVHC	Height	Width	Weight	Type	Body Material	Power Dissipation	Thermal Resistance @ Natural	Height Off Base (Height of Fin)	Attachment Method	Package Cooled	Thermal Resistance @ Forced Air Flow	Material Finish	Power Dissipation @ Temperature Rise
502303B00000	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Bolt	Aluminum	Rhombus	Bulk	2007	Active	Not Applicable	Black			1.630 41.40mm	RoHS Compliant	Lead Free						25.4mm	1.290 32.77mm		Board Level		8W		1.000 25.40mm	Bolt On			Black Anodized
574802B03700G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Clip, PC Pin, Solder	Aluminum	Rectangular, Fins		2007	Active	Not Applicable	Black	10.67mm		0.900 22.86mm	RoHS Compliant					TO-220		22.86mm	1.020 25.91mm		Board Level, Vertical			20.40°C/W	0.420 10.67mm	Clip and PC Pin	TO-220	6.00°C/W @ 500 LFM	Black Anodized	3.0W @ 60°C
321127B00000	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Threaded Coupling	Aluminum	Cylindrical		2007	Active	Not Applicable	Black		0.625 15.88mm OD		Non-RoHS Compliant	Lead Free	Lead, Tin			TO-5		6.88mm			Top Mount			54.00°C/W		Threaded Coupling	TO-5	25.00°C/W @ 200 LFM	Black Anodized	1.4W @ 70°C
342940	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	6 Weeks	Push Pin	Copper	Rectangular, Fins		2016	Active	Not Applicable				1.480 37.59mm	RoHS Compliant								1.516 38.50mm		Top Mount			15.90°C/W	0.551 14.00mm	Push Pin	BGA	2.60°C/W @ 200 LFM	AavSHIELD 3C
605202F00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Pin Fins		2016	Active	Not Applicable				48.000 1219.20mm	RoHS Compliant								1.312 33.32mm		Top Mount, Extrusion			0.90°C/W	9.875 250.82mm	Adhesive		0.25°C/W @ 700 LFM		15.0W @ 20°C
513301B02500G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins	Box	2007	Active	Not Applicable				2.500 63.50mm	RoHS Compliant	Lead Free				TO-218			1.375 34.93mm		Board Level, Vertical			8.00°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-218, TO-247	4.00°C/W @ 200 LFM	Black Anodized	8.0W @ 60°C
610852F00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum Alloy	Rectangular, Pin Fins		2016	Active	Not Applicable				48.000 1219.20mm	RoHS Compliant								5.380 136.65mm		Top Mount, Extrusion				1.312 33.32mm	Adhesive		0.50°C/W @ 500 LFM	Unfinished
560200B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Press Fit	Aluminum	Rectangular, Fins		2007	Active	Not Applicable	Black			0.890 22.61mm	RoHS Compliant							10.42mm	0.600 15.24mm		Top Mount			20.00°C/W	0.410 10.42mm	Press Fit, Slide On	14-DIP and 16-DIP	12.00°C/W @ 200 LFM	Black Anodized	1.0W @ 20°C
530122B00162G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip	Aluminum	Square, Angled Fins	Box	2007	Active	Not Applicable				1.750 44.45mm	RoHS Compliant	Lead Free				TO-220			0.490 12.44mm		Board Level, Vertical			6.20°C/W	1.750 44.45mm	Clip and Board Mounts	TO-220 (Dual)	1.50°C/W @ 400 LFM	Black Anodized	4.0W @ 30°C
575803B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rhombus		2007	Active	Not Applicable	Black	32.77mm		1.630 41.40mm	RoHS Compliant					TO-3		25.4mm	1.290 32.77mm		Board Level			11.00°C/W	1.000 25.40mm	Bolt On	TO-3	3.50°C/W @ 200 LFM	Black Anodized	5.0W @ 50°C
574102B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip	Aluminum	Rectangular, Fins	Bulk	2007	Active	Not Applicable	Black	21.84mm		0.750 19.05mm	RoHS Compliant	Lead Free		No		TO-220	No SVHC	19.05mm	0.860 21.84mm		Board Level			23.20°C/W	0.395 10.03mm	Clip	TO-220	8.00°C/W @ 500 LFM	Black Anodized	1.5W @ 40°C
647062	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1					Rectangular, Fins			Active	Not Applicable				4.252 108.00mm	RoHS Compliant								3.071 78.00mm		Top Mount				1.004 25.50mm	Bolt On	Intel® Xeon® CPU
553003B00000	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Square, Fins		2007	Active	Not Applicable	Black			1.780 45.21mm	Non-RoHS Compliant					TO-3		30.99mm	1.780 45.21mm		Board Level			6.60°C/W	1.220 31.00mm	Bolt On	TO-3	2.00°C/W @ 400 LFM	Black Anodized	4.0W @ 30°C
580100B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Press Fit	Aluminum	Rectangular, Fins		2007	Active	Not Applicable	Black	15.24mm		0.562 14.27mm	RoHS Compliant	Lead Free		No	8		No SVHC	11.43mm	0.600 15.24mm		Top Mount	Aluminium		30.00°C/W	0.450 11.43mm	Press Fit, Slide On	8-DIP	8.00°C/W @ 500 LFM	Black Anodized	1.0W @ 30°C
374724B00032G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	8 Weeks	Bolt	Aluminum	Square, Pin Fins	Bulk	2002	Active	Not Applicable	Black	35mm		1.378 35.00mm	RoHS Compliant	Lead Free				BGA	No SVHC	18mm	1.378 35.00mm		Top Mount	Metal		15.30°C/W	0.709 18.00mm	Thermal Tape, Adhesive (Included)	BGA	5.20°C/W @ 200 LFM	Black Anodized	3.0W @ 50°C
501000B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Adhesive	Aluminum	Rectangular, Fins		2007	Active	Not Applicable	Black			0.750 19.05mm	RoHS Compliant	Lead Free			14			5.39mm	0.604 15.34mm		Top Mount			60.00°C/W	0.212 5.39mm	Thermal Tape, Adhesive (Not Included)	14-DIP and 16-DIP	60.00°C/W @ 100 LFM	Black Anodized	0.6W @ 40°C
622002F00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Pin Fins		2016	Active	Not Applicable				48.000 1219.20mm	RoHS Compliant								3.500 88.90mm		Top Mount, Extrusion				0.850 21.60mm	Adhesive		1.50°C/W @ 200 LFM
529902B02500G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins	Bulk	2007	Active	Not Applicable	Black	25.4mm		2.000 50.80mm	RoHS Compliant	Lead Free		No		Radial	No SVHC	50.8mm	1.650 41.91mm		Board Level, Vertical			4.50°C/W	1.000 25.40mm	Bolt On and PC Pin	TO-220	1.50°C/W @ 500 LFM	Black Anodized	6.0W @ 30°C
6045BG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks						Active	Not Applicable		8.89mm		25.4mm	RoHS Compliant					TO-220					Passive
663652F00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Pin Fins		2016	Active	Not Applicable				48.000 1219.20mm	RoHS Compliant								1.500 38.10mm		Top Mount, Extrusion				0.630 16.00mm	Adhesive		2.00°C/W @ 400 LFM
513101B00000	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Bolt	Aluminum	Rectangular, Fins		2007	Active	Not Applicable				1.500 38.10mm	Non-RoHS Compliant								1.380 35.05mm		Board Level			11.00°C/W	0.500 12.70mm	Bolt On	TO-218	3.00°C/W @ 500 LFM	Black Anodized	8.0W @ 80°C
6273B	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Bolt, Through Hole	Aluminum	Rectangular, Fins			Active	Not Applicable	Black			0.750 19.05mm	Non-RoHS Compliant	Lead Free				TO-2	No SVHC	19.05mm	0.750 19.05mm	113.398093g	Board Level			21.00°C/W	0.375 9.52mm	Bolt On	TO-202	10.00°C/W @ 200 LFM	Black Anodized	1.5W @ 40°C
591302B02800G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PCB, Through Hole	Aluminum	Rectangular, Fins	Bulk	2007	Active	Not Applicable	Black	12.7mm		0.750 19.05mm	RoHS Compliant	Lead Free		No		TO-220	No SVHC	19.05mm	0.500 12.70mm		Board Level, Vertical			26.80°C/W	0.500 12.70mm	Clip and Board Locks	TO-220, TO-262	7.00°C/W @ 400 LFM	Black Anodized	1.0W @ 30°C
6236BG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip	Aluminum	Rectangular, Fins		2007	Active	Not Applicable	Black	12.95mm		0.700 17.78mm	RoHS Compliant	Lead Free		No		TO-220		17.78mm	0.520 13.21mm		Board Level, Vertical			25.00°C/W	0.510 12.95mm	Clip	TO-220	12.00°C/W @ 300 LFM	Black Anodized	2.0W @ 50°C
6396BG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Screw	Aluminum	Rectangular, Fins	Box	2007	Active	1 (Unlimited)	Black	25.4mm		1.000 25.40mm	RoHS Compliant	Lead Free		No	220	Radial	No SVHC	25.4mm	1.650 41.91mm		Board Level, Vertical			5.60°C/W	1.000 25.40mm	Bolt On and PC Pin	TO-220, TO-218	1.50°C/W @ 600 LFM	Black Anodized	4.0W @ 30°C
7178DG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Bolt, PC Pin, Screw	Copper	Rectangular, Fins		2007	Active	Not Applicable		9.52mm		0.750 19.05mm	RoHS Compliant	Lead Free				TO-220		19.05mm	0.520 13.21mm		Board Level, Vertical	Copper		35.70°C/W	0.375 9.52mm	Bolt On and PC Pin	TO-220	5.00°C/W @ 700 LFM	Tin	0.6W @ 30°C
593202B03400G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin	Aluminum	Rectangular, Fins		2007	Active	Not Applicable	Black			2.000 50.80mm	RoHS Compliant					TO-220		50.8mm	1.380 35.05mm		Board Level, Vertical			10.40°C/W	0.480 12.19mm	Bolt On and PC Pin	TO-220	5.00°C/W @ 200 LFM	Black Anodized	6.0W @ 60°C
6109BG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks					2007	Active	Not Applicable					RoHS Compliant					TO-220
531002B02100G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins		2007	Active	Not Applicable	Black			1.000 25.40mm	RoHS Compliant					Radial		25.94mm	1.375 34.93mm		Board Level, Vertical			13.40°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220	4.00°C/W @ 400 LFM	Black Anodized	2.0W @ 30°C
531102B02100G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins		2007	Active	Not Applicable	Black	12.7mm		1.500 38.10mm	RoHS Compliant	Lead Free	Tin			Radial	No SVHC	38.1mm	1.374 34.90mm		Board Level, Vertical			10.40°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220	4.00°C/W @ 300 LFM	Black Anodized	7.0W @ 70°C
