QS3244PAG Overview
This is a relatively small item of digital switch that is included in the TSSOP in order to save space on the board.Among its basic features are 20 terminations.In multiplexer's system, 5V is the voltage supplied.Signal switch has 20 component pins.A conductor terminates at GULL WING.In this case, the supply type is Single.It is configured with 20 pins.Surface Mount is the way it is mounted.As a result, signal multiplexer provides 8 bits.A power supply is provided for mux switch's normal operation of 5V.In electronic terms, the digital switch ic is classified as Bus Driver/Transceivers.Without any external influences, it consumes 3μA current of multiplexer ic at all times.Using a supply voltage of 5V can result in reliable performance of the multiplexers.A resistance of 2 is used to operate the signal switching.In terms of resistance, it has a value of 12Ohm.The signal switch can operate at a maximum temperature of 85°C.In order to maintain a minimal operating temperature, the temperature of the multiplexer should be set to -40°C.The device is specified to operate at a maximum supply voltage of 5.25V in accordance with the applicable device specification.A minimum supply voltage of 4.75V is specified for the digital swith by its applicable specification.BUS DRIVER is the logic integrated circuit used in the digitalswitch.
QS3244PAG Features
Supplied in the TSSOP package
Adopting a supply type of Single
Power supplies of 5V
Operating with the supply voltage of 5V
BUS DRIVER as the logic IC
QS3244PAG Applications
There are a lot of Integrated Device Technology (IDT) QS3244PAG Signal Switches / Multiplexers / Decoders applications.
