PI3C3126LEX
PI3C3126LEX
233-PI3C3126LEX
14-TSSOP (0.173, 4.40mm Width)
14 Terminations2.3V~3.6V 14 Pin 3126 Signal switch4 Functions
In Stock : 999
Share
Please send RFQ, we will respond immediately.
Product Details
Purchasing and Inquiry
PI3C3126LEX Overview
The reason it is provided is that the board space can be saved by placing digital switch in the 14-TSSOP (0.173, 4.40mm Width).It is packaged according to the Tape & Reel (TR) method.Surface Mount is the mounting method digital switch ic uses.The analog IC used in the multiplexers can be referred to as Bus Switch.When digital controlled switch operates at 2.3V~3.6V, designers have superior flexibility.As part of its basic configuration, 14 terminations are designed as a part of it.There is a base part number of 3126 which can also be used in order to locate the logic switch that are related to this item.In this case, 3.3V is the voltage supplied to the multiplexer's system.It employs GULL WING as the point at which conductors come to an end.As a type of supply, Single is employed.This multiplexer ic is configured with 14 pins.The multiplexer ic is mounted in the direction of Surface Mount.In the CB3Q/3VH/3C/2B family, the logic switch is included.There are 1 bits signal multiplexer provides.To prevent unnecessary failures, it is recommended that the minimum supply voltage (Vsup) remain at 2.97V.The maximal supply voltage (Vsup) should be kept at 3.63V to avoid some unnecessary failures.It is provided that 2.5/3.3V has a power supply in order to function normally.I would classify the digital switch ic as an electronic part belonging to the Bus Driver/Transceivers category.Without any external influences, it consumes 500μA current of multiplexer ic at all times.As far as the resistance is concerned, it operates with 2.A resistance of 8Ohm is used to operate it.The signal switch can operate at a maximum temperature of 85°C.In order to maintain a minimal operating temperature, the temperature of the multiplexer should be set to -40°C.Configuration elements for the mux switch consist of 4.
PI3C3126LEX Features
Supplied in the 14-TSSOP (0.173, 4.40mm Width) package
Adopting a supply type of Single
Power supplies of 2.5/3.3V
PI3C3126LEX Applications
There are a lot of Diodes Incorporated PI3C3126LEX Signal Switches / Multiplexers / Decoders applications.
- Analog, digital or video signal switching
- Automatic health monitoring systems
- RF-based home automation system
- CPU memory location identification
- Metal detectors
- Image transmission
- To select different devices in microprocessor output
- Electronic circuits
- Steel plants
- Data transfer
