Product Details
Purchasing and Inquiry
LV52206XA-MH Overview
In order to save board space, the 9-UFBGA, WLCSP package is used. For the design of these LED drivers, 2 outputs are used.We are using Surface Mount as the mounting method.-30°C~85°C TA is a valid operating temperature for the led driver.The benefits of Backlight are considerable.It operates with 9 terminations.It is configured with 9 pins as its base.There is a mounting of it by Surface Mount.It's under the LV52206 base part number.According to its characteristics, it is also classified into Display Drivers.The minimal input voltage is 2.7V.It is possible to supply current up to 5.5V.27mA is the maximum amount of current that can be supplied to the load.The electronic component can fully perform its functions if the switching frequency is maintained at 600kHz.A LED driver that operates at 21μA output current provides all the benefits of a LED driver.There's an interface IC marked with LED DISPLAY DRIVER on this part.The voltage at the output terminal is 40V.It is important to keep the output voltage below 30V.
LV52206XA-MH Features
Available in the 9-UFBGA, WLCSP package
Operating temperature of -30°C~85°C TA
Supply voltage of 3.6V
Switching frequency of 600kHz
Output voltage of 40V
LV52206XA-MH Applications
There are a lot of ON Semiconductor LV52206XA-MH LED Driver ICs applications.
- LED backlight driver for LCD displays for portable equipment
- Refrigeration lighting
- Medical surgery lighting
- LED Lightings for Industrial Equipment
- Panel lighting
- White LED Backlight for portable equipment
- Sports Facility Lighting
- LED backlight driver for LCD displays for Tablets and Note PCs
- Flicker-free LED Lighting using R1580N
- Replacement lamps
