Product Description: LTM4630EY-1B#PBF
The LTM4630EY-1B#PBF is a high-performance, dual 18A step-down DC-DC μModule® (power module) regulator from Analog Devices Inc. This complete power solution integrates power devices, inductors, and compensation components in a compact and thermally efficient package, simplifying the design process and reducing the required board space for power supply applications.
Features:
Dual Output: The LTM4630EY-1B#PBF provides two independent step-down outputs, each capable of delivering up to 18A of continuous output current.
Wide Input Voltage Range: This power module operates from a wide input voltage range, allowing it to support various input voltage sources and applications.
High Efficiency: With its synchronous rectification architecture and optimized design, the LTM4630EY-1B#PBF achieves high efficiency, reducing power dissipation and maximizing power conversion performance.
Compact and Thermally Efficient Package: The power devices, inductors, and capacitors are integrated into a compact, surface-mount package, ensuring excellent thermal performance and minimizing external component count.
Output Voltage Tracking: The module offers an option for output voltage tracking, enabling easy paralleling of multiple modules for higher output current or voltage.
Adjustable Output Voltage: The output voltage of each channel is programmable, allowing users to tailor the output voltage to the specific requirements of their application.
Programmable Switching Frequency: The switching frequency of the LTM4630EY-1B#PBF can be programmed or synchronized with an external clock, offering flexibility to optimize performance or reduce EMI.
Current Sharing: The power module provides the capability for current sharing between its two outputs, ensuring balanced load distribution.
Overcurrent and Thermal Protection: The LTM4630EY-1B#PBF incorporates comprehensive protection features, including overcurrent protection (OCP) and thermal shutdown, safeguarding the system from potential faults and overload conditions.
Applications:
The LTM4630EY-1B#PBF power module is ideal for various power supply applications that demand high efficiency, compactness, and ease of design. Some typical applications include:
Telecom and Networking Equipment: It is well-suited for powering networking switches, routers, and communication equipment.
Data Centers: The power module can be used in data center servers and storage systems.
Industrial Power Supplies: It is suitable for industrial power supplies that require stable and efficient voltage regulation, such as in motor drives and control systems.
Test and Measurement Instruments: The module is utilized in high-performance test and measurement equipment.
Computing and Embedded Systems: It is suitable for powering computing and embedded systems, including FPGA, DSP, and microcontroller-based applications.
High-Performance Audio Systems: The LTM4630EY-1B#PBF can be used in high-power audio amplifiers and sound systems.
In summary, the LTM4630EY-1B#PBF is a highly efficient, dual-output step-down DC-DC μModule® regulator that provides a compact and thermally efficient power solution for a wide range of applications. With its high current capability, wide input voltage range, adjustable output voltage, and current sharing capability, it is well-suited for various power supply applications in telecom, networking, data centers, industrial systems, computing, audio systems, and more. Its integrated features and comprehensive protection mechanisms make it a reliable and versatile choice for demanding power management needs.
