Home Home Integrated Circuits (ICs) Analog Switches & Multiplexers ICs DG3517DB-T5-E1
DG3517DB-T5-E1
  • DG3517DB-T5-E1
Free Sample More

DG3517DB-T5-E1

advertisement

Manufacturer No:

DG3517DB-T5-E1

Manufacturer:

Vishay Siliconix

HK JDW NO:

880-DG3517DB-T5-E1

Package:

10-WFBGA

Datasheet:

DG3517DB-T5-E1

Description:

45ns, 42ns SPDT 2.9Ohm BOTTOM Analog Switches BREAK-BEFORE-MAKE DG3517 10 Pins 2nA 3V 10-WFBGA

Quantity:

Add to RFQ list

In Stock : 999

Share

Please send RFQ, we will respond immediately.

* Contact Name

* Business Email

* Company Name

* Country

* Quantity

Product Details

Purchasing and Inquiry

DG3517DB-T5-E1 Overview


Shipping overseas is convenient due to the electrical component's packing in 10-WFBGA. High reliability is ensured by the advanced packaging method Tape & Reel (TR). This analog switch is mounted in Surface Mount. In the multiplexer and demultiplexer, 2:1 represents the number of circuits. Operating temperature around -40°C~85°C TA extended. There are 10 terminations totally. By its 1 channels, the electronic component provides high-quality output. In the case of a voltage supply of 3V volts, the electrical part can be powered up and run. It is injected into the electrical part body with 10 pins. Circuits based on SPDT switching are used to construct these analog switch ics. This multiplexer is composed of 2 circuits. DG3517 can be used to search for analog multiplexer variants. As far as internal resistance is concerned, it has 2.9Ohm. Datasheets for 10 pin functions are available upon request. It is a typical Multiplexer or Switches analog multiplexer. normally, users should not supply switches with voltages higher than 5.5V. The digital multiplexer has a low cost Single supply. It is recommended that the electrical component receives a voltage of 1.8V. For this multiplexer to operate, 1μA current would be sufficient. Draining from a single voltage supply, this analog switch requires a voltage of 1.8V~5.5V. The analogue multiplexer may be damaged if voltage is greater than 1μA. It is possible to use SEPARATE OUTPUT outputs on this digital multiplexer.

DG3517DB-T5-E1 Features


1 Channels
Switch Circuit: SPDT
1μA Supply Current
-3db Bandwidth: 300MHz

DG3517DB-T5-E1 Applications


There are a lot of Vishay Siliconix DG3517DB-T5-E1 Analog Switches & Multiplexers ICs applications.

  • Industrial
  • Signal routing between systems
  • Multiplexers
  • Medical
  • Transmit
  • Voice over IP/DSL – Integrated Access Devices, Smart
  • Fiber to the Home
  • Precision instrumentation
  • Avionics
  • Medical systems
1. Purchase

You can send an inquiry by email, or add the item to the RFQ list and submit it to us.
Tell us the model and quantity you need, our sales staff will reply the price in time.
EmailEmail for receiving inquiries: jindawei@hkjdwchip.com

2. Means of Payment

For your convenience, we accept multiple payment methods in USD, including PayPal, Credit Card, and wire transfer.

3. RFQ (Request for Quotations)

It is recommended to request for quotations to get the latest prices and inventories about the part.
Our sales will reply to your request by email within 24 hours.

IMPORTANT NOTICE

1. You'll receive an order information email in your inbox. (Please remember to check the spam folder if you didn't hear from us).
2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

4. Shipping Cost

Shipping starts at $40, but some countries will exceed $40. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)
The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and country.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, and UPS.

Delivery Time

Once the goods are shipped, estimated delivery time depends on the shipping methods you chose:
FedEx International, 5-7 business days.
The following are some common countries' logistic time.

Purchasing and Inquiry

Payment Method

 The fee is charged according to the rule of PayPal.
East West Bank charge US$30.00 banking fee.
The fee is charged according to the rule of PayPal.
Western Union charge US$0.00 banking fee.

Shipping

 DHL(www.dhl.com)
From $40.00 basic shipping fee depend on zone and country.
UPS(www.ups.com)
From $40.00 basic shipping fee depend on zone and country.
FedEx(www.fedex.com)
From $40.00 basic shipping fee depend on zone and country.
Registered Mail(www.singpost.com)
From $10.00 basic shipping fee depend on different zone and country.

Package

Product
Step1Product
Casing drivepipe
Step2Casing drivepipe
Anti-static bag
Step3Anti-static bag
Packaging boxes
Step4Packaging boxes
Bar-code shipping tag
Step5Bar-code shipping tag

DG3517DB-T5-E1

technical specifications, attributes, parameters and parts with similar specifications to DG3517DB-T5-E1.

  • Type
    Parameter
    Select All

  • Mount

    Surface Mount

  • Mounting Type

    Surface Mount

  • Package / Case

    10-WFBGA

  • Number of Pins

    10

  • Operating Temperature

    -40°C~85°C TA

  • Packaging

    Tape & Reel (TR)

  • Published

    2016

  • JESD-609 Code

    e1

  • Pbfree Code

    yes

  • Part Status

    Obsolete

  • Moisture Sensitivity Level (MSL)

    1 (Unlimited)

  • Number of Terminations

    10

  • Resistance

    2.9Ohm

  • Terminal Finish

    TIN SILVER COPPER

  • Subcategory

    Multiplexer or Switches

  • Max Power Dissipation

    457mW

  • Terminal Position

    BOTTOM

  • Terminal Form

    BALL

  • Peak Reflow Temperature (Cel)

    260

  • Number of Functions

    2

  • Supply Voltage

    3V

  • Terminal Pitch

    0.5mm

  • Time@Peak Reflow Temperature-Max (s)

    40

  • Base Part Number

    DG3517

  • Output

    SEPARATE OUTPUT

  • Pin Count

    10

  • Power Supplies

    3/5V

  • Number of Channels

    1

  • Number of Circuits

    2

  • Max Supply Voltage

    5.5V

  • Min Supply Voltage

    1.8V

  • Operating Supply Current

    1μA

  • Max Supply Current

    1μA

  • Turn On Delay Time

    51 ns

  • Supply Type

    Single

  • Turn-Off Delay Time

    45 ns

  • -3db Bandwidth

    300MHz

  • On-State Resistance (Max)

    2.9Ohm

  • Multiplexer/Demultiplexer Circuit

    2:1

  • Off-state Isolation-Nom

    54 dB

  • Current - Leakage (IS(off)) (Max)

    2nA

  • Channel Capacitance (CS(off), CD(off))

    12pF

  • On-state Resistance Match-Nom

    0.25Ohm

  • Switch Circuit

    SPDT

  • Switch Time (Ton, Toff) (Max)

    45ns, 42ns

  • Charge Injection

    1pC

  • Channel-to-Channel Matching (ΔRon)

    250m Ω (Max)

  • Crosstalk

    -78dB @ 1MHz

  • Switching

    BREAK-BEFORE-MAKE

  • Switch-off Time-Max

    46ns

  • Voltage - Supply, Single (V+)

    1.8V~5.5V

  • Normal Position

    NC

  • Height Seated (Max)

    0.753mm

  • Radiation Hardening

    No

  • RoHS Status

    ROHS3 Compliant
