AT90CAN12816AU

AT90CAN128-16AU Overview

Packaged in a 64-TQFP format. This Microcontroller has 53 I/Os. It is important to note that the Microcontroller has a Surface Mount mounting type. This Microcontroller is based on the 8-Bit core. The type of memory it uses for its program is FLASH. The temperature range of this Microcontroller is within the range of -40°C~85°C TA. AVR® 90CAN series components belong to this electrical component. 128KB 128K x 8 is the size of its program memory. With a AVR Core Processor, Microcontroller is fast and efficient. During the manufacture of the IC chip, there is a number 64 of terminations. This part works in a 8-bit manner. Input voltage for the chip is 5V volts. The Microcontroller chip has NO DMA channels. The part has a memory size of 128kB. Alternatives can be found by looking at the base part number AT90CAN128. At a frequency of 16MHz, Microcontroller can operate efficiently. It is possible for the device to work with the motor using the PWM channel YES. On the chip, 64 pins are accessible. The clock has 4 timers or counters on it. There is EEPROM, FLASH memory on this piece of equipment. As a result of its RISC core architecture, it can be used in many applications. A total of 8 ADC channels are present in this device. 1 channels of I2C have been incorporated into the design of the part.

The high-performance, low-power Microchip 8-bit AVR RISC-basedmicrocontroller combines 128 KB ISP flash memory, 4KB EEPROM, 4KB SRAM, 53 general purpose I/O lines, 32 general purpose working registers, CAN controller (V2.0A/V2.0B compliant), real time counter, four flexible timer/counters with compare modes and PWM, two USARTs, byte oriented two-wire serial interface, an 8-channel 10-bit A/D converter with optional differential input stage with programmable gain, programmable watchdog timer with internal oscillator, SPI serial port, JTAG test interface (IEEE 1149.1 compliant) for on-chip debugging, and five software selectable power saving modes. The device supports a throughput of 16 MIPS at 16 MHz and operates between 2.7-5.5 volts. By executing powerful instructions in a single clock cycle, the device achieves throughputs approaching 1 MIPS per MHz, balancing power consumption and processing speed.

AT90CAN128-16AU Features

64-TQFP package
Mounting type of Surface Mount
Microcontrollers subcategory

AT90CAN128-16AU Applications

There are a lot of Microchip Technology AT90CAN128-16AU Microcontroller applications.

• Tape drives
• Aerospace navigation systems
• 3D printers
• Playstation
• Smartphone
• Nintendo
• Temperature sensing and controlling devices
• Hand-held metering systems
• Smart highways
• Printers
