AMC1301DWVR
AMC1301DWVR
feilidi-AMC1301DWVR
8-SOIC (0.295, 7.50mm Width)
13mA per Channel 60μA Instrumentational OP Amps 3V~5.5V AMC1301 8-SOIC (0.295, 7.50mm Width)
Unit Price: $13.0704
Ext Price: $13.0704
In Stock : 2000
Share
Qty
Unit Price
Ext Price
-
10
$12.33
$123.31
-
100
$11.63
$1,163.26
-
500
$10.97
$5,487.10
-
1000
$10.35
$10,353.00
Not the price you want? Send RFQ Now and we'll contact you ASAP.
Product Details
Purchasing and Inquiry
AMC1301DWVR Description
The AMC1301DWVR is a precision, isolated amplifier with an isolation barrier that is highly resistant to magnetic interference between the output and the input circuitry. According to VDE V 0884-10 and UL1577, this barrier is certified to provide reinforced galvanic isolation of up to 7 kVPEAK. This device prevents noise currents on a high common-mode voltage line from entering the local ground and interfering with or destroying sensitive equipment when used in conjunction with an isolated power supply. The AMC1301DWVR's input is designed to connect directly to shunt resistors or other low-voltage signal sources. The device's high performance enables accurate current management, resulting in system-level power savings and lower torque ripple, particularly in motor control applications. The AMC1301DWVR's inherent common-mode overvoltage and missing high-side supply voltage detection functions make system design and debugging easier. The AMC1301DWVR is available in a wide-body 8-pin SOIC (DWV) package and is fully specified for the extended industrial temperature range of –40°C to +125°C.
AMC1301DWVR Features
Fixed Gain: 8.2
System-Level Diagnostic Features
3.3-V Operation on High-Side and Low-Side
Low Offset Error and Drift: ±200 μV at 25°C, ± 3 μV/°C
±250-mV Input Voltage Range Optimized for Current Measurement Using Shunt Resistors
AMC1301DWVR Applications
Isolated Voltage Sensing
Shunt-Resistor-Based Current Sensing In:
– Motor Drives
– Frequency Inverters
– Uninterruptible Power Supplies
