AM29LV008BT-120EI
AM29LV008BT-120EI
AMD / AM29LV008BT-120EI
TSOP
Flash, 1MX8, 120ns, PDSO40, MO-142CD, TSOP-40
In Stock : 10000
Share
Please send RFQ, we will respond immediately.
Product Details
Purchasing and Inquiry
GENERAL DESCRIPTION
DISTINCTIVE CHARACTERISTICS
— Full voltage range: 2.7 to 3.6 volt read and write operations for battery-powered applications
— Regulated voltage range: 3.0 to 3.6 volt read and write operations and for compatibility with high performance 3.3 volt microprocessors
■ Manufactured on 0.32 µm process technology
— Compatible with 0.5 µm Am29LV008 device
■ High performance
— Full voltage range: access times as fast as 90 ns
— Regulated voltage range: access times as fast as 70 ns
■ Ultra low power consumption (typical values at 5 MHz)
— 200 nA Automatic Sleep mode current
— 200 nA standby mode current
— 7 mA read current
— 15 mA program/erase current
■ Flexible sector architecture
— One 16 Kbyte, two 8 Kbyte, one 32 Kbyte, and fifteen 64 Kbyte sectors
— Supports full chip erase
— Sector Protection features:
A hardware method of locking a sector to prevent any program or erase operations within that sector
Sectors can be locked in-system or via programming equipment
Temporary Sector Unprotect feature allows code changes in previously locked sectors
■ Unlock Bypass Program Command
— Reduces overall programming time when issuing multiple program command sequences
■ Top or bottom boot block configurations available
■ Embedded Algorithms
— Embedded Erase algorithm automatically preprograms and erases the entire chip or any combination of designated sectors
— Embedded Program algorithm automatically writes and verifies data at specified addresses
■ Minimum 1,000,000 write cycle guarantee per sector
■ 20-year data retention at 125°C
— Reliable operation for the life of the system
■ Package option
— 40-pin TSOP
■ Compatibility with JEDEC standards
— Pinout and software compatible with singlepower supply Flash
— Superior inadvertent write protection
■ Data# Polling and toggle bits
— Provides a software method of detecting program or erase operation completion
■ Ready/Busy# pin (RY/BY#)
— Provides a hardware method of detecting program or erase cycle completion
■ Erase Suspend/Erase Resume
— Suspends an erase operation to read data from, or program data to, a sector that is not being erased, then resumes the erase operation
■ Hardware reset pin (RESET#)
— Hardware method to reset the device to reading array data
