  • ADS1258IRTCR

ADS1258IRTCR

advertisement

Manufacturer No:

ADS1258IRTCR

Manufacturer:

Texas Instruments

HK JDW NO:

815-ADS1258IRTCR

Package:

48-VFQFN Exposed Pad

Datasheet:

ADS1258IRTCR

Description:

24 Bit 0.5mm Gold ADC ADS1258 2.5V 48-VFQFN Exposed Pad

Quantity:

In Stock : 4045

Share

Please send RFQ, we will respond immediately.

* Contact Name

* Business Email

* Company Name

* Country

* Quantity

Product Details

Purchasing and Inquiry

Product Description: ADS1258IRTCR


The ADS1258IRTCR is a highly integrated, low-noise, and high-precision analog-to-digital converter (ADC) designed for demanding measurement and data acquisition applications. This versatile ADC offers exceptional performance and a wide range of features, making it suitable for a variety of precision instrumentation and control systems.


Key Features:


High Resolution: The ADS1258IRTCR boasts a high-resolution of up to 24 bits, allowing for extremely precise measurements.


Low Noise: Designed with low noise characteristics, it ensures accurate capture of even the smallest analog signals.


Low Power: This ADC is optimized for low power consumption, making it ideal for battery-powered and portable devices.


Programmable Gain Amplifier (PGA): It includes a PGA with selectable gain settings, enabling flexible signal conditioning and measurement.


Data Rate Control: The data rate can be adjusted to suit the specific requirements of the application, balancing speed and power consumption.


Internal Voltage Reference: It features an internal voltage reference, simplifying the design and calibration process.


Applications:


The ADS1258IRTCR is well-suited for precision measurement and control applications, including:


Industrial Automation: It is commonly used in industrial automation systems for monitoring and controlling sensors, transducers, and process variables.


Medical Instruments: The high precision and low noise characteristics make it suitable for medical instruments such as patient monitors, infusion pumps, and diagnostic equipment.


Data Acquisition Systems: The ADC is often integrated into data acquisition systems used in laboratories and research environments for accurate data collection.


Instrumentation: Precision instrumentation devices like multimeters, oscilloscopes, and spectrum analyzers benefit from the high-resolution data provided by this ADC.


Keyboard Compatibility (Note: This ADC is not directly related to keyboards):


While the ADS1258IRTCR is not typically used directly in keyboard applications, it can indirectly relate to keyboards in scenarios where highly precise analog measurements are necessary. For example, in advanced keyboards with integrated biometric sensors (e.g., fingerprint scanners) or pressure-sensitive keypads, an ADC like this could be used to convert analog sensor data into digital form for processing.


It's important to note that this ADC is primarily designed for applications requiring high precision and accuracy in analog-to-digital conversion, and its direct use in keyboards is relatively uncommon.


1. Purchase

You can send an inquiry by email, or add the item to the RFQ list and submit it to us.
Tell us the model and quantity you need, our sales staff will reply the price in time.
EmailEmail for receiving inquiries: jindawei@hkjdwchip.com

2. Means of Payment

For your convenience, we accept multiple payment methods in USD, including PayPal, Credit Card, and wire transfer.

3. RFQ (Request for Quotations)

It is recommended to request for quotations to get the latest prices and inventories about the part.
Our sales will reply to your request by email within 24 hours.

IMPORTANT NOTICE

1. You'll receive an order information email in your inbox. (Please remember to check the spam folder if you didn't hear from us).
2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

4. Shipping Cost

Shipping starts at $40, but some countries will exceed $40. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)
The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and country.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, and UPS.

Delivery Time

Once the goods are shipped, estimated delivery time depends on the shipping methods you chose:
FedEx International, 5-7 business days.
The following are some common countries' logistic time.

Purchasing and Inquiry

Payment Method

The fee is charged according to the rule of PayPal.
East West Bank charge US$30.00 banking fee.
The fee is charged according to the rule of PayPal.
Western Union charge US$0.00 banking fee.

Shipping

DHL(www.dhl.com)
From $40.00 basic shipping fee depend on zone and country.
UPS(www.ups.com)
From $40.00 basic shipping fee depend on zone and country.
FedEx(www.fedex.com)
From $40.00 basic shipping fee depend on zone and country.
Registered Mail(www.singpost.com)
From $10.00 basic shipping fee depend on different zone and country.

Package

Product
Step1Product
Casing drivepipe
Step2Casing drivepipe
Anti-static bag
Step3Anti-static bag
Packaging boxes
Step4Packaging boxes
Bar-code shipping tag
Step5Bar-code shipping tag

ADS1258IRTCR

technical specifications, attributes, parameters and parts with similar specifications to ADS1258IRTCR.

  • Type
    Parameter
    Select All
  • ECCN Code

    EAR99

  • Operating Supply Voltage

    5V

  • Length

    7mm

  • RoHS Status

    ROHS3 Compliant

  • Lead Free

    Lead Free

  • Contact Plating

    Gold

  • Radiation Hardening

    No

  • Number of Pins

    48

  • Package / Case

    48-VFQFN Exposed Pad

  • Max Supply Voltage

    5.25V

  • Min Supply Voltage

    4.75V

  • Height

    900μm

  • Width

    7mm

  • Thickness

    900μm

  • Mounting Type

    Surface Mount

  • Operating Temperature

    -40°C~105°C

  • Input Type

    Differential, Single Ended

  • Max Supply Voltage (DC)

    5.25V

  • Min Supply Voltage (DC)

    2.7V

  • Number of Functions

    1

  • JESD-609 Code

    e4

  • Terminal Position

    QUAD

  • Peak Reflow Temperature (Cel)

    260

  • Supply Voltage

    2.5V

  • Base Part Number

    ADS1258

  • Pin Count

    48

  • Surface Mount

    YES

  • Terminal Pitch

    0.5mm

  • Subcategory

    Analog to Digital Converters

  • Power Supplies

    +-2.53.3V

  • Max Power Dissipation

    62mW

  • Configuration

    MUX-ADC

  • Polarity

    Bipolar, Unipolar

  • Power Dissipation

    42mW

  • Max Dual Supply Voltage

    2.65V

  • Min Dual Supply Voltage

    2.15V

  • Number of Inputs

    8, 16

  • Power Consumption

    42mW

  • Dual Supply Voltage

    2.5V

  • Resolution

    3 B

  • Number of Bits

    24

  • Supply Type

    Analog, Digital, Dual, Single

  • Number of Analog In Channels

    16

  • Output Bit Code

    2'S COMPLEMENT BINARY

  • Number of A/D Converters

    1

  • Output Format

    SERIAL

  • Negative Supply Voltage-Nom

    -2.5V

  • Sampling Rate

    125 ksps

  • Conversion Rate

    125 ksps

  • Differential Nonlinearity

    1 LSB

  • Converter Type

    ADC, DELTA-SIGMA

  • Architecture

    Sigma-Delta

  • Reference Type

    External

  • Data Interface

    SPI

  • Sampling Rate (Per Second)

    125k

  • Voltage - Supply, Digital

    2.7V~5.25V

  • Factory Lead Time

    6 Weeks

  • Lifecycle Status

    ACTIVE (Last Updated: 5 days ago)

  • Packaging

    Tape & Reel (TR)

  • Pbfree Code

    yes

  • Part Status

    Active

  • Moisture Sensitivity Level (MSL)

    2 (1 Year)

  • Number of Terminations

    48
