AC Fans

Name	Manufacturer	Quantity	Datasheet	Factory Lead Time	Mount	Material	Housing Material	Packaging	Published	Series	Part Status	Moisture Sensitivity Level (MSL)	Termination	Max Operating Temperature	Min Operating Temperature	Depth	Operating Supply Voltage	Length	RoHS Status	Lead Free	Voltage - Rated	Current Rating	Radiation Hardening	Additional Feature	Package / Case	REACH SVHC	Reach Compliance Code	Frequency	Height	Width	Approval Agency	Thickness	Weight	Operating Temperature	Size / Dimension	Voltage Range	Ratings	Voltage - Rated AC	Ingress Protection	Power Rating	Max Power Dissipation	Feature	Current Rating (Amps)	Lifetime @ Temp	Speed	Power Consumption	Air Flow	Power (Watts)	Material - Frame	Material - Blade	RPM	Bearing Type	Fan Type	Noise	Static Pressure	Thermal Support Device Type	Rated Power	Life Expectancy
109S013UL	Sanyo Denki America Inc.	RFQ Min: 1 Mult: 1						Bulk		San Ace 120	Active	Not Applicable	2 Wire Leads						ROHS3 Compliant		100VAC										CE, CSA, PSE, TUV, UL		1.3lbs 589.7g	-22~140°F -30°C~60°C	Square - 120mm Lx120mm H							Locked Rotor Protection	0.140A	25000 Hrs @ 60°C			60.8 CFM (1.70m3/min)	11.00W	Aluminum	Plastic	2000 RPM		Tubeaxial	32.0 dB(A)	0.106 in H2O (26.4 Pa)
ASEN90212	Panasonic Industrial Automation Sales	RFQ Min: 1 Mult: 1	download						2006		Obsolete	1 (Unlimited)	2 Wire Leads								115VAC										CSA, UL			14~140°F -10°C~60°C	Square - 92.5mm Lx92.5mm H								0.130A				35.0 CFM (0.980m3/min)	10.00W	Aluminum	Plastic	3100 RPM	Ball	Tubeaxial	39.0 dB(A)
OA80AP-11-2TB	Orion Fans	RFQ Min: 1 Mult: 1	download	15 Weeks	Flanges		Aluminium		2010	OA80	Active	1 (Unlimited)	2 Terminals						ROHS3 Compliant		115VAC	120mA			Axial			5.06kHz	80mm		cURus, TUV	38mm		-4~176°F -20°C~80°C	Square - 80mm Lx80mm H	103V~126VAC				9W	9W		0.120A	60000 Hrs @ 40°C			25.0 CFM (0.700m3/min)	9.00W	Aluminum	Polybutylene Terephthalate (PBT)	2400 RPM	Ball	Tubeaxial	32.0 dB	0.160 in H2O (39.8 Pa)
D4E200-CA08-41	ebm-papst Inc.	RFQ Min: 1 Mult: 1	download	20 Weeks						D4E200	Active	1 (Unlimited)							RoHS Compliant																																		Blower, Centrifugal
OA119AP-11-1WB	Orion Fans	RFQ Min: 1 Mult: 1	download	15 Weeks			Aluminium	Box	2010	OA119	Active	1 (Unlimited)	2 Wire Leads						ROHS3 Compliant	Lead Free	115VAC				Axial				127mm		cURus, TUV	38.1mm		-4~176°F -20°C~80°C	Square - 127mm Lx127mm H	80V~130VAC				12W	14W			60000 Hrs @ 40°C			130.0 CFM (3.64m3/min)	14.00W	Aluminum	Polybutylene Terephthalate (PBT)	3000 RPM	Ball	Tubeaxial	46.0 dB	0.240 in H2O (59.8 Pa)
FDA2-17255NBHW3F-SF	Qualtek	RFQ Min: 1 Mult: 1		14 Weeks					2015	HPLC, FDA2-17255-SF	Active	1 (Unlimited)	2 Wire Leads						ROHS3 Compliant		115VAC										CE, cURus, TUV		1.874lb 850g	-4~158°F -20°C~70°C	Rectangular/Rounded - 172mm Lx151mm H				IP56M - Dust Protected, Water Resistant			Salt Fog Rated, Thermal Overload Protector (TOP)	0.210A				240.0 CFM (6.72m3/min)	25.00W	Aluminum	Plastic	3100 RPM	Ball	Tubeaxial	61.0 dB(A)	0.531 in H2O (132.3 Pa)
UF12B12-BTLR	Mechatronics Fan Group	RFQ Min: 1 Mult: 1	download	12 Weeks					2001	UF12B	Active	1 (Unlimited)	2 Terminals						RoHS Compliant		115VAC									25.00mm	CE, cUL, TUV, UL		0.725lb 328.85g	-40~158°F -40°C~70°C	Square - 120mm Lx120mm H								0.110A	50000 Hrs @ 25°C			53.0 CFM (1.48m3/min)	11.00W	Aluminum	Polybutylene Terephthalate (PBT)	2000 RPM	Ball	Tubeaxial	33.0 dB(A)	0.110 in H2O (27.4 Pa)
4715FS-23T-B3A-D00	NMB Technologies Corporation	RFQ Min: 1 Mult: 1	download	18 Weeks					2009	FS	Active	1 (Unlimited)	2 Terminals						RoHS Compliant		230VAC	90mA			Axial						CE, CSA, TUV, UL		1.2lbs 544.3g	14~158°F -10°C~70°C	Square - 119mm Lx119mm H						12W		0.090A				90.0 CFM (2.52m3/min)	12.00W	Aluminum	Plastic	2650 RPM	Ball	Tubeaxial	39.0 dB	0.220 in H2O (54.8 Pa)
W2E142-BB01-87	ebm-papst Inc.	RFQ Min: 1 Mult: 1	download	20 Weeks	Flanges		Aluminium	Bulk		W2E142	Active	1 (Unlimited)	2 Terminals			150mm	230V		ROHS3 Compliant	Lead Free	230VAC	130mA	No		Axial			5.06kHz	38mm				2lbs 907.2g	-40~176°F -40°C~80°C	Rectangular/Rounded - 172mm Lx150mm H					57W	28W		0.130A			25W	230.0 CFM (6.44m3/min)	28.00W	Aluminum	Steel		Ball	Tubeaxial	57.0 dB(A)		AC FAN
W3G800-GV01-67F	ebm-papst Inc.	RFQ Min: 1 Mult: 1	download							Green Tech W3G800	Active	1 (Unlimited)							ROHS3 Compliant		480VAC	3.9A									UL		112lbs 50.8kg	-13~150°F -25°C~65°C	Square - 970mm Lx970mm H	380V~480VAC	IP54, Water Resistant		IP54 - Dust Protected, Water Resistant		2.98kW	Electronic Commutation (EC)					16450 CFM (460.6m3/min)	2980W	Aluminum		1090 RPM		Tubeaxial
11938FB-B3J-AA-00	NMB Technologies Corporation	RFQ Min: 1 Mult: 1	download	18 Weeks					2013	FS	Active	1 (Unlimited)	2 Wire Leads						RoHS Compliant		230VAC													14~158°F -10°C~70°C	Square - 119mm Lx119mm H								0.050A	100000 Hrs @ 25°C			70.0 CFM (1.96m3/min)	9.00W	Aluminum	Plastic	1900 RPM	Ball	Tubeaxial	33.0 dB	0.120 in H2O (30.0 Pa)
OA109EC-UR-1TB	Orion Fans	RFQ Min: 1 Mult: 1	download	16 Weeks						OA109EC	Active	Not Applicable	2 Terminals						ROHS3 Compliant		115/230VAC										CE, cURus, UR		0.64lb 290.3g	-4~158°F -20°C~70°C	Square - 120mm Lx120mm H	90V~265VAC						Dual Voltage, Electronic Commutation (EC), Thermal Overload Protector (TOP)	0.060A/0.080A	60000 Hrs @ 40°C			106.0 CFM (2.97m3/min)	4.90W 5.20W	Polybutylene Terephthalate (PBT)	Polybutylene Terephthalate (PBT)	3200 RPM	Ball	Tubeaxial	43.0 dB(A)	0.340 in H2O (84.7 Pa)
FKA1-17251QBHW31	Qualtek	RFQ Min: 1 Mult: 1	download	16 Weeks			Aluminium		2013	FKA1-17251	Active	1 (Unlimited)	2 Wire Leads				230V		ROHS3 Compliant		230VAC	230mA			Axial		unknown		150mm		CE, cURus, TUV		2.3lbs 1kg	14~158°F -10°C~70°C	Rectangular/Rounded - 172mm Lx150mm H					230mW	50.6W		0.230A				189.0 CFM (5.29m3/min)		Aluminum	Plastic	2700 RPM	Ball	Tubeaxial	57.7 dB(A)	0.408 in H2O (101.6 Pa)	AC FAN
R87F-A4A13LP	Omron Electronics Inc-EMC Div	RFQ Min: 1 Mult: 1	download	5 Weeks	Flanges		Aluminium		2008	R87F	Active	1 (Unlimited)	2 Terminals						RoHS Compliant		200VAC	55mA			Axial		unknown	5.06kHz	25mm		CSA, UL		0.772lb 350.17g	-22~158°F -30°C~70°C	Square - 120mm Lx120mm H					1.21kW	12W		0.055A				53.5 CFM (1.50m3/min)	12.00W	Aluminum	Polycarbonate (PC)	1700 RPM	Ball	Tubeaxial	32.0 dB	0.079 in H2O (19.6 Pa)	AC FAN
UF90DPB12-H1S2A	Mechatronics Fan Group	RFQ Min: 1 Mult: 1	download	12 Weeks					2014	UF90DPB	Active	1 (Unlimited)	2 Wire Leads						RoHS Compliant		115VAC									37.20mm	CE, cUL, TUV, UL		1.4lbs 635g	-40~140°F -40°C~60°C	Square - 120mm Lx120mm H							Thermal Overload Protector (TOP)	0.210A				21.0 CFM (0.588m3/min)	18.00W	Aluminum	Polyamide (PA), Nylon	2700 RPM	Ball	Blower, Centrifugal	51.0 dB(A)	0.500 in H2O (124.5 Pa)
ASEN10211	Panasonic Industrial Automation Sales	RFQ Min: 1 Mult: 1							2006		Obsolete	1 (Unlimited)	2 Wire Leads	140°C	14°C				RoHS Compliant		100VAC	180mA								25.50mm			0.794lb 360.15g	14~140°F -10°C~60°C	Square - 119mm Lx119mm H						11W		0.180A				70.6 CFM (1.98m3/min)	11.00W	Aluminum	Plastic	2700 RPM	Ball	Tubeaxial	38.0 dB(A)
FKA2-28089NBHT3F	Qualtek	RFQ Min: 1 Mult: 1	download	16 Weeks					2013	FKA2-28089	Active	1 (Unlimited)	2 Terminals	158°C	14°C				ROHS3 Compliant		115VAC	2.6A			Axial					89.00mm	CE, TUV, UL		7.7lbs 3.5kg	14~158°F -10°C~70°C	Square - 280mm Lx280mm H						260W		2.60A				1400.0 CFM (39.20m3/min)	260W	Aluminum	Plastic	3000 RPM	Ball	Tubeaxial	78.0 dB(A)	0.044 in H2O (11.0 Pa)
R3G500-AG25-64F	ebm-papst Inc.	RFQ Min: 1 Mult: 1	download							Green Tech R3G500	Active	1 (Unlimited)							ROHS3 Compliant		380V~480VAC	3.3A									UL		50lbs 22.7kg	-13~140°F -25°C~60°C	Round - 505mm Dia	380V~480VAC	IP54, Water Resistant		IP54 - Dust Protected, Water Resistant		2.5kW	Electronic Commutation (EC), Thermal Overload Protector (TOP)					6450 CFM (180.6m3/min)	2500W	Aluminum		1700 RPM		Motorized Impellers, 3 Phase
4890N	ebm-papst Inc.	RFQ Min: 1 Mult: 1	download	20 Weeks	Flanges	Metal				4000N	Active	1 (Unlimited)	2 Terminals			119mm	230V		RoHS Compliant	Lead Free	230VAC		No	APPROVALS: UL; VDE	Axial	No SVHC		50Hz	38mm		CE, CSA, UL, VDE		1.2lbs 544.3g	14~158°F -10°C~70°C	Square - 119mm Lx119mm H			230V		11W	11W			55000 Hrs @ 40°C		11W	47.0 CFM (1.32m3/min)	11.00W			1550 RPM	Sintec	Tubeaxial	25.0 dB(A)		AC FAN		27500 h
CF4113HBL-000U-AA9	Sunon Fans	RFQ Min: 1 Mult: 1	download	14 Weeks					2016	CF	Active	Not Applicable	2 Wire Leads	158°C	-13°C				ROHS3 Compliant		110/230VAC									38.00mm	CE, CUR, TUV, UL		0.595lb 269.89g	-13~158°F -25°C~70°C	Square - 120mm Lx120mm H	90V~265VAC	IP21		IP21		5.1W	Auto Restart, Electronic Commutation (EC), Dual Voltage	0.056/0.081A				109.0 CFM (3.05m3/min)	5.10W	Polybutylene Terephthalate (PBT)	Polybutylene Terephthalate (PBT)	3500 RPM	Ball	Tubeaxial	44.9 dB(A)	0.370 in H2O (92.2 Pa)
FDA2-25489QBLW4F	Qualtek	RFQ Min: 1 Mult: 1		17 Weeks			Steel		2014	HPLC, FDA2-25489	Active	1 (Unlimited)	2 Wire Leads	158°C	-4°C			254mm	ROHS3 Compliant		230VAC	140mA			Axial				254mm	89.00mm	CE, cURus, TUV		6lbs 2.7kg	-4~158°F -20°C~70°C	Round - 254mm Dia					32W	32W		0.140A	50000 Hrs @ 25°C			440.0 CFM (12.32m3/min)	32.00W	Aluminum	Steel	1650 RPM	Ball	Tubeaxial	52.0 dB(A)	0.307 in H2O (76.5 Pa)
UF15P12-BTLR	Mechatronics Fan Group	RFQ Min: 1 Mult: 1	download	12 Weeks					2016	UF15P	Active	Not Applicable	2 Terminals						RoHS Compliant		115VAC										CE, cUL, TUV, UL		1.8lbs 816.5g	-40~158°F -40°C~70°C	Rectangular/Rounded - 172mm Lx150mm H								0.150A				106.0 CFM (2.97m3/min)	31.00W	Aluminum	Polybutylene Terephthalate (PBT)	1700 RPM	Ball	Tubeaxial	37.0 dB(A)	0.220 in H2O (54.8 Pa)
19028608A	Comair Rotron	RFQ Min: 1 Mult: 1									Obsolete	Not Applicable
ASEN50754	Panasonic Industrial Automation Sales	RFQ Min: 1 Mult: 1							2006		Obsolete	1 (Unlimited)	2 Terminals								200VAC												1.8lbs 816.5g	14~140°F -10°C~60°C	Rectangular/Rounded - 172mm Lx150mm H								0.210A				214.3 CFM (6.00m3/min)	33.00W	Aluminum	Plastic	3200 RPM	Ball	Tubeaxial	56.0 dB(A)
OA225LFG111T	Orion Fans	RFQ Min: 1 Mult: 1	download	16 Weeks			Aluminium			OA225	Active	1 (Unlimited)	Terminal Block						ROHS3 Compliant	Lead Free	115VAC	700mA							320mm		cURus, TUV			-40~176°F -40°C~80°C	Square - 320mm Lx320mm H	100V~125VAC	IP55, Water Resistant		IP55 - Dust Protected, Water Resistant	72W	72W	Kit	0.700A	40000 Hrs @ 40°C			600.0 CFM (16.80m3/min)	72.0W	Aluminum	Metal	2800 RPM	Ball	Tubeaxial	59.0 dB(A)	0.550 in H2O (137.0 Pa)
FKA2-25489QBMW3F	Qualtek	RFQ Min: 1 Mult: 1		16 Weeks					2013	FKA2-25489	Active	1 (Unlimited)	2 Wire Leads						ROHS3 Compliant		230VAC	140mA			Axial		unknown				CE, cURus, TUV		4.4lbs 2kg	14~158°F -10°C~70°C	Round - 254mm Dia						28.8W		0.140A				530.0 CFM (14.84m3/min)	28.80W	Aluminum	Plastic	1600 RPM	Ball	Tubeaxial	57.0 dB(A)	0.322 in H2O (80.2 Pa)	AC FAN
UF15PC23-BWHNR	Mechatronics Fan Group	RFQ Min: 1 Mult: 1	download	12 Weeks					2015	UF15PC	Active	Not Applicable	2 Wire Leads						RoHS Compliant		230VAC										CE, cUL, TUV, UL		1.8lbs 816.5g	-40~158°F -40°C~70°C	Rectangular/Rounded - 172mm Lx150mm H				IP55 - Dust Protected, Water Resistant			Permanent Split Capacitor Motor, Thermal Overload Protector (TOP)	0.120A				226.0 CFM (6.33m3/min)	29.00W	Aluminum	Polybutylene Terephthalate (PBT)	3400 RPM	Ball	Tubeaxial	58.0 dB(A)	0.790 in H2O (196.8 Pa)
4710PS-22T-B30-B00	NMB Technologies Corporation	RFQ Min: 1 Mult: 1	download	18 Weeks			Aluminium		2004	PS	Active	1 (Unlimited)	2 Terminals			119mm			RoHS Compliant	Lead Free	220VAC	80mA	No		Axial				25.4mm	105mm	CE, CSA, UL, VDE		0.8lb 362.87g	14~158°F -10°C~70°C	Square - 119mm Lx119mm H						11W		0.080A	50000 Hrs @ 25°C	2300 rpm		70.6 CFM (1.98m3/min)	11.00W	Aluminum	Polycarbonate (PC), Fiberglass Reinforced	2700 RPM	Ball	Tubeaxial	38.0 dB	0.165 in H2O (41.1 Pa)	AC FAN	14W
5915PC-20T-B30-SM0	NMB Technologies Corporation	RFQ Min: 1 Mult: 1	download	18 Weeks			Aluminium		2009	PC	Active	1 (Unlimited)	2 Terminals			172mm			RoHS Compliant		200VAC	210mA	No		Axial				38mm		CE, CSA, UL, VDE		1.9lbs 861.8g	14~158°F -10°C~70°C	Rectangular/Rounded - 172mm Lx150mm H						33W		0.210A	50000 Hrs @ 25°C			211.8 CFM (5.93m3/min)	33.00W	Aluminum	Polycarbonate (PC), Fiberglass Reinforced	3200 RPM	Ball	Tubeaxial	56.0 dB	0.863 in H2O (215.0 Pa)
UF15AC12-BTHR-CC	Mechatronics Fan Group	RFQ Min: 1 Mult: 1	download	12 Weeks					2014	UF15AC	Active	1 (Unlimited)	2 Terminals						RoHS Compliant		115VAC									38.00mm	CE, cUL, TUV, UL		1.6lbs 725.7g	-40~158°F -40°C~70°C	Rectangular/Rounded - 172mm Lx150mm H							Conformal Coating, Permanent Split Capacitor Motor, Thermal Overload Protector (TOP)	0.230A				212.0 CFM (5.94m3/min)	28.00W	Aluminum	Polybutylene Terephthalate (PBT)	3400 RPM	Ball	Tubeaxial	58.0 dB(A)	0.750 in H2O (186.8 Pa)
