Slide Switches

Name	Manufacturer	Quantity	Datasheet	Factory Lead Time	Mount	Housing Material	Packaging	Published	Series	Pbfree Code	Part Status	Moisture Sensitivity Level (MSL)	Termination	Number of Positions	ECCN Code	Max Operating Temperature	Min Operating Temperature	Orientation	Length	RoHS Status	Lead Free	Contact Material	Contact Plating	Voltage - Rated	Current Rating	Radiation Hardening	Package / Case	Reach Compliance Code	Height	Width	Mounting Type	Operating Temperature	Voltage - Rated DC	Voltage - Rated AC	HTS Code	Packing Method	Contact Resistance	Insulation Resistance	Max Voltage Rating (DC)	JESD-609 Code	Surface Mount	Body Length or Diameter	Body Breadth	Body Height	Termination Style	Contact Style	Dielectric Withstanding Voltage	Feature	Current Rating (Amps)	Throw Configuration	Switch Type	Sealing	Contact Current(AC)-Max	Contact (AC) Max Rating R Load	Contact Current(DC)-Max	Contact Voltage(DC)-Max	Contact (DC) Max Rating R Load	PCB Hole Count	Electrical Life	Switch Function	Contact Current Rating	Contact Finish	Actuator Type	Mechanical Life	Circuit	Actuator Length	Actuator Material	Contact Timing	Operating Force	Switch Travel
S-1-Z	Nidec Copal Electronics	RFQ Min: 1 Mult: 1		9 Weeks	Panel		Bulk		S		Active	1 (Unlimited)	Solder							ROHS3 Compliant					8A						Panel Mount			125V											Solder Lug	Non-Shorting			8A AC	DPDT									10,000 Cycles	On-On			Standard		DPDT	9.00mm		Non-Shorting (BBM)		5.00mm
AS1D-5M-10-Z	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	9 Weeks	Through Hole		Tray		AS		Active	1 (Unlimited)	PC Pin			85°C	-20°C	Right Angle		ROHS3 Compliant			Gold		50mA						Through Hole, Right Angle	-20°C~85°C	48V	48V											PC Pin	Non-Shorting			50mA AC/DC	SPDT									10,000 Cycles	On-On	50mA	Gold	Standard		SPDT	4.30mm		Non-Shorting (BBM)	70 ~ 500gf	2.20mm
CL-SB-22B-01	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	11 Weeks	Surface Mount		Bulk	2016	CL-SB	yes	Active	1 (Unlimited)	Gull Wing							ROHS3 Compliant		Copper			200mA			unknown			Surface Mount	-40°C~85°C	12V							e4					Gull Wing	Non-Shorting			200mA DC		SLIDE SWITCH								10,000 Cycles	On-On	200mA	Silver	Standard		DPDT	2.00mm	Polyamide (PA), Nylon	Non-Shorting (BBM)	153gf
SS210N-Z	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	9 Weeks	Panel		Bulk	2016	SS		Active	1 (Unlimited)	Solder							ROHS3 Compliant					10A						Panel Mount			125V											Solder Lug				10A AC	DPDT									10,000 Cycles	On-On			Standard		DPDT	9.00mm		Not Specified		9.00mm
ES125D10-Z	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download		Panel		Bulk	2016	ES		Obsolete	1 (Unlimited)	Screw							ROHS3 Compliant					25A						Panel Mount			125V											Screw Terminal	Non-Shorting			25A AC	SPDT									20,000 Cycles	On-On			Standard		SPDT	9.00mm		Non-Shorting (BBM)		8.00mm
AS2N-6M-10-Z	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	9 Weeks	Through Hole		Tray	2016	AS		Active	1 (Unlimited)	PC Pin			85°C	-20°C			ROHS3 Compliant			Gold		50mA						Through Hole, Right Angle	-20°C~85°C	48V	48V											PC Pin	Non-Shorting			50mA AC/DC	DPDT									10,000 Cycles	On-On		Gold	Standard		DPDT	4.30mm		Non-Shorting (BBM)	70 ~ 500gf	2.20mm
CL-SB-12B-02	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	11 Weeks	Surface Mount		Bulk	2016	CL-SB	yes	Active	1 (Unlimited)	Gull Wing							ROHS3 Compliant	Lead Free	Copper			200mA			unknown			Surface Mount	-40°C~85°C	12V												Gull Wing	Non-Shorting			200mA DC		SLIDE SWITCH								10,000 Cycles	On-On	200mA	Gold	Standard		SPDT	2.00mm	Polyamide (PA), Nylon	Non-Shorting (BBM)	153gf
ES215N12-Z	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download		Panel		Bulk	2016	ES		Obsolete	1 (Unlimited)	Solder							ROHS3 Compliant					15A						Panel Mount			125V											Solder Lug	Non-Shorting			15A AC	DPDT									20,000 Cycles	On-On			Standard		DPDT	9.00mm		Non-Shorting (BBM)		8.00mm
CL-SB-12B-11	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	11 Weeks	Surface Mount		Bulk	2016	CL-SB		Active	1 (Unlimited)	Gull Wing			85°C	-40°C			ROHS3 Compliant		Copper	Silver		200mA						Surface Mount, Right Angle	-40°C~85°C	12V												Gull Wing	Non-Shorting			200mA DC	SPDT									10,000 Cycles	On-On	200mA	Silver	Standard		SPDT	2.00mm	Polyamide (PA), Nylon	Non-Shorting (BBM)	153gf	2.00mm
MHS122	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	9 Weeks	Through Hole		Bulk	2016	MHS		Active	1 (Unlimited)	PC Pin			70°C	-10°C		9.6mm	ROHS3 Compliant			Silver	12V	200mA				3.5mm	5.8mm	Through Hole, Right Angle	-10°C~70°C	12V												PC Pin	Non-Shorting			200mA DC	SPDT									5,000 Cycles	On-On		Silver	Standard		SPDT	2.00mm		Non-Shorting (BBM)	50 ~ 250gf	2.00mm
8SS2011-Z	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	9 Weeks	Panel		Bulk	2016	8SS		Active	1 (Unlimited)	Solder			85°C	-30°C	Vertical		ROHS3 Compliant			Silver		4A						Panel Mount	-30°C~85°C	30V	125V											Solder Lug	Non-Shorting			6A AC 4A DC	DPDT									30,000 Cycles	On-On		Silver	Standard	100,000 Cycles	DPDT	5.00mm		Non-Shorting (BBM)		2.60mm
CSS-1312TB	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	10 Weeks	PCB, Surface Mount		Tape & Reel (TR)	2006	CSS	yes	Active	1 (Unlimited)	Gull Wing					Right Angle		ROHS3 Compliant		Copper Alloy			100mA	No	SMD/SMT				Surface Mount, Right Angle	-20°C~70°C	12V						12V						Gull Wing	Non-Shorting			100mA DC		SLIDE SWITCH								10,000 Cycles	Mom-On-Mom	100mA	Gold	Standard		SP3T	2.00mm	Liquid Crystal Polymer (LCP)	Non-Shorting (BBM)	102 ~ 357gf
ES225N-Z	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download		Panel		Bulk	2016	ES		Obsolete	1 (Unlimited)	Quick Connect							ROHS3 Compliant					25A						Panel Mount			125V											Quick Connect - 0.250 (6.3mm)	Non-Shorting			25A AC	DPDT									20,000 Cycles	On-On			Standard		DPDT	9.00mm		Non-Shorting (BBM)		8.00mm
CL-SB-22A-02T	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	11 Weeks	Surface Mount		Tape & Reel (TR)	2012	CL-SB	yes	Active	1 (Unlimited)						Vertical		ROHS3 Compliant		Copper			200mA			unknown			Surface Mount	-40°C~85°C	12V			TR, 13 INCH				e4		8.5mm	3.5 mm	3.5mm	J Lead	Non-Shorting			200mA DC		SLIDE SWITCH				0.2A		.2A@12VDC		10,000 Cycles	On-On	200mA	Gold	Standard		DPDT	2.00mm	Polyamide (PA), Nylon	Non-Shorting (BBM)	153gf
CL-SB-13B-11T	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	11 Weeks	Surface Mount		Tape & Reel (TR)		CL-SB		Active	1 (Unlimited)	Gull Wing			85°C	-40°C			ROHS3 Compliant		Copper	Silver		200mA						Surface Mount, Right Angle	-40°C~85°C	12V												Gull Wing	Non-Shorting			200mA DC	SP3T									10,000 Cycles	On-On-On		Silver	Standard		SP3T	2.00mm	Polyamide (PA), Nylon	Non-Shorting (BBM)	160/260gf	2.00mm
CL-SB-13A-11	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	11 Weeks	Surface Mount		Bulk	2016	CL-SB		Active	1 (Unlimited)				85°C	-40°C			ROHS3 Compliant		Copper	Silver		200mA						Surface Mount, Right Angle	-40°C~85°C	12V												J Lead	Non-Shorting			200mA DC	SP3T									10,000 Cycles	On-On-On		Silver	Standard		SP3T	2.00mm	Polyamide (PA), Nylon	Non-Shorting (BBM)	160/260gf	2.00mm
CL-SB-13B-02T	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	11 Weeks	Surface Mount		Tape & Reel (TR)	2012	CL-SB		Active	1 (Unlimited)	Gull Wing			85°C	-40°C	Vertical		ROHS3 Compliant	Lead Free	Copper	Gold		200mA						Surface Mount	-40°C~85°C	12V												Gull Wing	Non-Shorting			200mA DC	SP3T									10,000 Cycles	On-On-On	200mA	Gold	Standard		SP3T	2.00mm	Polyamide (PA), Nylon	Non-Shorting (BBM)	160/260gf	2.00mm
CL-SB-13B-02	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	11 Weeks			Bulk	2016	CL-SB	yes	Active	1 (Unlimited)			EAR99					ROHS3 Compliant		Copper									Surface Mount	-40°C~85°C	12V		8536.50.90.50	TR, 13 INCH				e4	NO	12mm	3.5 mm	3.5mm	Gull Wing				200mA DC		SLIDE SWITCH	MOISTURE PROOF			0.2A	12V			10,000 Cycles	On-On-On		Gold	Standard		SP3T	2.00mm	Polyamide (PA), Nylon	Non-Shorting (BBM)	160/260gf
CL-SA-12C-22	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	11 Weeks	Through Hole		Bulk	2016	CL-SA		Active	1 (Unlimited)	PC Pin			85°C	-40°C	Vertical		ROHS3 Compliant	Lead Free	Gold (Au)			500mA						Through Hole	-40°C~85°C	12V												PC Pin	Non-Shorting			500mA DC	SPDT									2,000 Cycles	On-On	500mA		Standard	10,000 Cycles	SPDT	1.40mm		Non-Shorting (BBM)	255gf	1.60mm
CSS-1311MC	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	10 Weeks	Through Hole		Tube	2006	CSS	yes	Active	1 (Unlimited)	PC Pin					Right Angle		ROHS3 Compliant		Copper Alloy			100mA			unknown			Through Hole, Right Angle	-20°C~70°C	12V						12V						PC Pin	Non-Shorting			100mA DC		SLIDE SWITCH								10,000 Cycles	On-On-Mom		Gold	Standard		SP3T	2.00mm	Liquid Crystal Polymer (LCP)	Non-Shorting (BBM)	102 ~ 357gf
MHS131	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	9 Weeks	Through Hole		Bulk	2016	MHS		Active	1 (Unlimited)	PC Pin			70°C	-10°C			ROHS3 Compliant			Silver		200mA						Through Hole	-10°C~70°C	12V												PC Pin	Non-Shorting			200mA DC	SP3T									5,000 Cycles	On-On-On		Silver	Standard		SP3T	2.00mm		Non-Shorting (BBM)	50 ~ 400gf	2.00mm
CL-SB-23A-12T	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	11 Weeks	Surface Mount		Tape & Reel (TR)	2012	CL-SB		Active	1 (Unlimited)				85°C	-40°C			ROHS3 Compliant		Copper	Gold		200mA						Surface Mount, Right Angle	-40°C~85°C	12V												J Lead	Non-Shorting			200mA DC	DP3T									10,000 Cycles	On-On-On		Gold	Standard		DP3T	2.00mm	Polyamide (PA), Nylon	Non-Shorting (BBM)	160/260gf	2.00mm
CL-SA-12C4-22	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	11 Weeks	Through Hole		Bulk	2016	CL-SA		Active	1 (Unlimited)	PC Pin			85°C	-40°C	Right Angle		ROHS3 Compliant		Gold (Au)			500mA						Through Hole, Right Angle	-40°C~85°C	12V												PC Pin	Non-Shorting			500mA DC	SPDT									2,000 Cycles	On-On	500mA		Standard	10,000 Cycles	SPDT	1.40mm		Non-Shorting (BBM)	255gf	1.60mm
CAS-D20A	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	11 Weeks	Surface Mount		Bulk		CAS		Active	1 (Unlimited)	J-Hook			85°C	-40°C			RoHS Compliant		Copper Alloy	Gold			No	SMD/SMT				Surface Mount	-40°C~85°C	6V						24V						J Lead			Tape Seal	100mA DC	DPDT									2,000 Cycles	On-On	100mA	Gold	Flush		SPDT x 2	Flush	Polyamide (PA), Nylon	Not Specified	51 ~ 510gf	0.60mm
8SS2012-Z	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	9 Weeks	Through Hole		Bulk	2016	8SS		Active	1 (Unlimited)	PC Pin			85°C	-30°C	Vertical		ROHS3 Compliant			Silver		4A						Through Hole	-30°C~85°C	30V	125V											PC Pin	Non-Shorting			6A AC 4A DC	DPDT									30,000 Cycles	On-On		Silver	Standard	100,000 Cycles	DPDT	5.00mm		Non-Shorting (BBM)		2.60mm
CL-SA-12C4-02	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	11 Weeks	Through Hole		Bulk	2016	CL-SA		Active	1 (Unlimited)	PC Pin			85°C	-40°C			ROHS3 Compliant	Lead Free	Gold (Au)			500mA						Through Hole, Right Angle	-40°C~85°C	12V												PC Pin	Non-Shorting			500mA DC	SPDT									2,000 Cycles	On-On			Standard	10,000 Cycles	SPDT	1.40mm		Non-Shorting (BBM)	255gf	1.60mm
CUS-22TB	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	10 Weeks	Surface Mount	LIQUID CRYSTAL POLYMER	Tape & Reel (TR)	2006	CUS		Active	1 (Unlimited)	Gull Wing	1	EAR99			Vertical		ROHS3 Compliant		Copper Alloy			300mA	No	SMD/SMT				Surface Mount	-20°C~70°C	4V				0.07mOhm	100000000Ohm	20V	e4		6.7056mm	4.0894 mm	1.397mm	Gull Wing	Non-Shorting	100VAC V		300mA DC		SLIDE SWITCH				0.3A		0.3A@4VDC	2	10,000 Cycles	On-On	300mA	Gold	Standard		DPDT	1.50mm	Polyamide (PA), Nylon	Non-Shorting (BBM)	204gf
CL-SB-13C-11	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	11 Weeks	Through Hole		Bulk		CL-SB		Active	1 (Unlimited)	PC Pin			85°C	-40°C			ROHS3 Compliant		Copper	Silver		200mA						Through Hole, Right Angle	-40°C~85°C	12V												PC Pin	Non-Shorting			200mA DC	SP3T									10,000 Cycles	On-On-On		Silver	Standard		SP3T	2.00mm	Polyamide (PA), Nylon	Non-Shorting (BBM)	160/260gf	2.00mm
CL-SB-12A-12T	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	11 Weeks	Surface Mount		Tape & Reel (TR)	2012	CL-SB		Active	1 (Unlimited)				85°C	-40°C	Horizontal		ROHS3 Compliant		Copper	Gold		200mA						Surface Mount, Right Angle	-40°C~85°C	12V												J Lead	Non-Shorting			200mA DC	SPDT									10,000 Cycles	On-On	200mA	Gold	Standard		SPDT	2.00mm	Polyamide (PA), Nylon	Non-Shorting (BBM)	153gf	2.00mm
ASE1E-2M-10-Z	Nidec Copal Electronics	RFQ Min: 1 Mult: 1	download	9 Weeks	Through Hole		Tray		ASE		Active	1 (Unlimited)	PC Pin		EAR99			Vertical		ROHS3 Compliant					50mA			unknown			Through Hole	-20°C~85°C	60V	60V	8536.50.90.50	BULK						9.5mm	5 mm	8mm	PC Pin	Non-Shorting		Washable	50mA AC/DC		SLIDE SWITCH	WATER PROOF	0.05A	.05A@60VAC	0.05A		.05A@60VDC		10,000 Cycles	On-Off-On	50mA	Gold	Standard		SPDT	2.80mm		Non-Shorting (BBM)	70 ~ 500gf	2.20mm
