Magnetic Components
Magnetic components are electronic components that utilize magnetic fields to perform various functions in electronic circuits. These components include inductors, transformers, and chokes, which are used to store and transfer energy in the form of magnetic fields. Inductors are used to filter out unwanted signals and noise, while transformers are used to step up or step down voltage levels. Chokes are used to block high-frequency signals and prevent them from interfering with other components in the circuit. Magnetic components are essential in many electronic devices, including power supplies, audio equipment, and telecommunications systems. They are available in various sizes and shapes, and their performance is dependent on the materials used and the design of the component.
Accessory Type
